The John Deere 4010, manufactured from 1960 to 1963, was a game-changer for agriculture. Powered by a 71 HP diesel or gasoline engine, it delivered a reliable 62 PTO horsepower. Its Synchro Range transmission and responsive hydraulics made it a popular choice for farmers looking for increased productivity in the field.

The John Deere 4010 was introduced in 1960 as part of the New Generation series, replacing the 730. Production continued through 1963, setting a new standard for tractor performance and operator comfort. Engine options included a John Deere 4.2L (254 ci) 4-cylinder diesel engine producing approximately 71 horsepower, or a John Deere 4.0L (242 ci) 4-cylinder gasoline engine, also rated around 71 horsepower. The standard transmission was a Synchro Range transmission offering 8 forward and 2 reverse gears. The independent PTO delivered 62 horsepower at 540 RPM. Hydraulic capacity was around 15 GPM, powering two rear remotes. It featured a Category II 3-point hitch, enabling the use of a wider range of implements. Farmers utilized the 4010 for a variety of tasks, including row crop work, hay production, livestock operations, and light tillage. The 4010 distinguished itself from earlier models with its modern styling, improved ergonomics, and more powerful engine, setting the stage for future John Deere advancements.

Specifications

Engine	John Deere 4.2L (254 ci) Diesel 71 HP / John Deere 4.0L (242 ci) Gas 71 HP
PTO HP	62 HP @ 540 RPM
Transmission	Synchro Range 8 Forward / 2 Reverse
Hydraulics	15 GPM, 2 remotes
3-Point Hitch	Category II, 3,400 lbs
Fuel Capacity	26 gallons
Weight	7,450 lbs
Years Produced	1960-1963

Maintenance Tips

Change engine oil and filter every 125-250 hours of operation, depending on operating conditions and oil type. Use a high-quality oil meeting John Deere specifications.
Inspect hydraulic fluid levels regularly and change the hydraulic filter every 500 hours. Check for leaks and address them promptly to prevent system damage.
Periodically drain and flush the fuel tank to remove sediment and water. Inspect fuel lines and filters for clogs or damage. Use fuel additives to prevent gelling in cold weather.
Before storing the tractor for an extended period, add fuel stabilizer to the fuel tank, change the engine oil and filter, and grease all fittings. Store the tractor in a dry, sheltered location.

History & Background

The John Deere 4010 debuted in 1960 as part of John Deere's "New Generation" of tractors, representing a significant leap forward in design and engineering. There were no major redesigns during its relatively short production run. The 4010 is remembered as a pivotal model that helped modernize farming practices and solidify John Deere's reputation for innovation.

Frequently Asked Questions

What engine is in the John Deere 4010?

The John Deere 4010 came with either a 4.2L (254 ci) 4-cylinder diesel engine rated at 71 HP or a 4.0L (242 ci) 4-cylinder gasoline engine, also rated at 71 HP.

What is the PTO horsepower on a 4010?

The John Deere 4010 has a PTO horsepower rating of 62 HP at 540 RPM.

What oil filter fits the 4010?

The John Deere 4010 typically uses a John Deere oil filter part number AR26344. Cross-references include Fram PH2870A, Wix 51794, or equivalent.

What are common parts needed for the 4010?

Common parts needed for the 4010 include engine oil filters, fuel filters, air filters, hydraulic filters, fan belts, hydraulic seals, tie rod ends, drag links, clutch discs, and pressure plates.
