John Deere 3310 Tractor Parts

3310 parts and accessories

The John Deere 3310 tractor, produced from 2001 to 2007, provided dependable power to farmers. Powered by a Yanmar 3TNV84 diesel engine producing around 30 HP, it delivered a PTO horsepower of approximately 25 HP. This compact utility tractor was prized for its versatility in various farming tasks, from mowing and light tillage to loader work and general farm maintenance.

The John Deere 3310 was a compact utility tractor manufactured between 2001 and 2007. It was designed to provide an affordable and versatile solution for small to medium-sized farms and agricultural operations. The tractor is powered by a Yanmar 3TNV84 diesel engine. This engine boasts a displacement of 1.3 liters (79.3 cubic inches) and delivers approximately 30 horsepower. The 3310 featured a mechanical transmission, typically an 8-speed forward and 8-speed reverse synchronized transmission, which offered a good range of speeds for various tasks. It also included a shuttle shift for easy directional changes. The PTO horsepower is rated at around 25 HP, operating at 540 RPM. The hydraulic system offers a flow rate of approximately 6.3 GPM and typically includes one or two rear remotes. The 3-point hitch is a Category I, with a lift capacity of around 1433 lbs. Common farming applications for the John Deere 3310 include mowing, light tillage operations, haying, livestock management, and operating implements like rotary cutters, tillers, and post-hole diggers. Its compact size and maneuverability differentiate it from larger John Deere models, making it suitable for smaller acreages and tasks requiring precision.

Specifications

Engine	Yanmar 3TNV84 30 HP Diesel
PTO HP	25 HP @ 540 RPM
Transmission	Mechanical 8F/8R
Hydraulics	6.3 GPM, 1-2 remotes
3-Point Hitch	Category I, 1433 lbs lift capacity
Fuel Capacity	7.4 gallons
Weight	2260 lbs
Years Produced	2001-2007

Maintenance Tips

Engine Oil & Filter: Change the engine oil and filter every 250 hours of operation using the recommended John Deere oil and filter. Regularly check oil levels.
Hydraulic System: Inspect hydraulic fluid levels regularly and change the hydraulic fluid and filter every 500 hours. Check for leaks around hoses and fittings.
Fuel System: Use clean, high-quality diesel fuel and replace the fuel filter annually. Drain any water that may accumulate in the fuel tank to prevent corrosion and injector problems.
Seasonal Storage: Before storing the tractor for extended periods, stabilize the fuel with a fuel stabilizer, grease all lubrication points, and store it in a dry location, preferably under cover. Disconnect the battery to prevent drainage.

History & Background

The John Deere 3310 was introduced in 2001 as part of John Deere's compact utility tractor lineup, providing a versatile and affordable option for smaller farms. The model remained largely unchanged throughout its production run, proving to be a reliable and popular choice for farmers needing a robust, smaller horsepower tractor. It helped solidify John Deere's presence in the compact tractor market.

Frequently Asked Questions

What engine is in the John Deere 3310?

The John Deere 3310 is equipped with a Yanmar 3TNV84 diesel engine, producing approximately 30 horsepower with a displacement of 1.3 liters (79.3 cubic inches).

What is the PTO horsepower on a 3310?

The PTO horsepower on the John Deere 3310 is approximately 25 HP, operating at 540 RPM.

What oil filter fits the 3310?

The recommended oil filter for the John Deere 3310 is typically a John Deere M806418 or equivalent. Common cross-references include Fram PH6022 or Wix 51394.

What are common parts needed for the 3310?

Common wear parts for the John Deere 3310 include engine oil filters, fuel filters, air filters, hydraulic filters, belts (fan, alternator), hydraulic seals, steering components (tie rod ends), clutch parts (if applicable), and PTO clutches.

Showing 97-115 of 115 products

Sort by:
