John Deere 1520 Tractor Parts

Jump to Parts

The John Deere 1520 tractor, manufactured from 1973 to 1975, was a popular utility tractor renowned for its reliability and versatility. Powered by a 36 horsepower diesel engine, it provided ample power for various farm tasks. Its PTO horsepower of 31.5 made it well-suited for operating implements like mowers and tillers, making it a valuable asset for farmers of all sizes.

The John Deere 1520 was introduced in 1973 as a part of John Deere's utility tractor lineup, filling a crucial niche for smaller farms and diverse agricultural applications. Production continued until 1975. This model was equipped with a Yanmar 3T80 diesel engine, a 101.7 cubic inch (1.7L) three-cylinder engine producing approximately 36 horsepower. The transmission was typically a gear-type transmission with 8 forward and 2 reverse speeds, offering a good range for different tasks. The PTO delivered 31.5 horsepower, typically operating at 540 RPM. The hydraulic system had a capacity of around 6.3 GPM, providing adequate power for implements. It featured a Category I 3-point hitch, capable of lifting around 1800 lbs. The 1520 was commonly used for tasks like mowing, light tillage, haying operations, and general utility work around livestock farms. Compared to larger models like the 2030 or 3020, the 1520 offered a more compact size and lower operating costs, making it an attractive option for small-scale farming and hobby farms.

Specifications

Engine	Yanmar 3T80 36 HP Diesel
PTO HP	31.5 HP @ 540 RPM
Transmission	Gear, 8 forward and 2 reverse
Hydraulics	6.3 GPM, 2 remotes (optional)
3-Point Hitch	Category I, 1800 lbs lift capacity
Fuel Capacity	12.5 gallons
Weight	2870 lbs
Years Produced	1973-1975

Maintenance Tips

Engine Oil & Filter: Change the engine oil and filter every 200-250 hours of operation using an oil that meets John Deere specifications. Regular oil changes are crucial for engine longevity.
Hydraulic System: Inspect hydraulic fluid levels and check for leaks regularly. Replace hydraulic filters according to the manufacturer's recommendations (typically every 500 hours) to prevent contamination and maintain hydraulic performance.
Fuel System: Use clean, high-quality diesel fuel. Drain the fuel sediment bowl regularly to remove water and contaminants that can damage the fuel injection system. Consider using a fuel additive for seasonal storage to prevent fuel degradation.

History & Background

The John Deere 1520 was released in 1973, aiming to provide a compact and economical tractor option. It offered a blend of power and maneuverability suited for smaller farms. While it had a relatively short production run, the 1520 remains a testament to John Deere's commitment to meeting the diverse needs of agricultural operations.

Frequently Asked Questions

What engine is in the John Deere 1520?

The John Deere 1520 is powered by a Yanmar 3T80 3-cylinder diesel engine. It produces approximately 36 horsepower and has a displacement of 101.7 cubic inches (1.7L).

What is the PTO horsepower on a 1520?

The PTO horsepower on the John Deere 1520 is 31.5 HP at 540 RPM.

What oil filter fits the 1520?

The John Deere oil filter part number for the 1520 is typically a TY21744 or AM101207. Common cross-references include Wix 51348 or NAPA 1348.

What are common parts needed for the 1520?

Common wear parts for the John Deere 1520 include engine oil filters, fuel filters, hydraulic filters, belts (fan belt, alternator belt), hydraulic seals (for cylinders and pumps), steering components (tie rod ends, ball joints), and clutch components (clutch disc, pressure plate).
