John Deere S685 Combine Parts

S685 parts and accessories

The John Deere S685 combine, produced from approximately 2012 to 2017, was a popular choice for farmers needing a high-capacity machine. Sporting a powerful engine around 431 HP and available with header widths ranging from 30 to 40 feet, the S685 excelled in diverse harvesting conditions. Its rotary separator design made it particularly effective for handling high-yielding crops.

The John Deere S685 combine was introduced as part of the S600 series, known for its enhanced productivity and advanced technology. Production years ranged roughly from 2012 to 2017. Powering the S685 is a John Deere PowerTech 9.0L engine, producing approximately 431 horsepower with a displacement of 549 cubic inches (9.0L). This engine delivers the necessary power for demanding harvesting operations. The S685 utilizes a single rotor separator system designed for high-capacity threshing and separating. The grain tank holds around 330 bushels, and the unloading auger boasts a rate of approximately 3.3 bushels per second (198 bu/min). Available header widths ranged from 30 to 40 feet, accommodating various field sizes and crop types. Chopper and spreader options were available to manage residue efficiently. The cab features advanced technology for operator comfort and control, including a touch screen display and automated harvesting settings. The S685 is well-suited for harvesting corn, soybeans, wheat, and other small grains.

Specifications

Engine	John Deere PowerTech 9.0L 431 HP Diesel
Separator Type	Rotary - Single Rotor
Grain Tank	330 bushels
Unloading Rate	198 bu/min
Header Widths	30-40 ft
Fuel Capacity	250 gallons
Weight	Approximately 36,000 lbs
Years Produced	2012-2017 (approximate)

Maintenance Tips

Concave Adjustment: Regularly check and adjust concave clearance according to the crop being harvested. Proper concave settings minimize grain loss and damage.
Belt and Chain Tension: Inspect belt and chain tension regularly, especially before and during harvest. Loose belts and chains can lead to slippage, reduced performance, and premature wear.
Sieve and Chaffer Cleaning: Clean sieves and chaffers daily to prevent clogging and ensure optimal grain cleaning. Remove any accumulated debris and adjust settings as needed.
Bearing Greasing: Grease all bearings according to the manufacturer's recommendations. Proper lubrication prevents bearing failure and extends the lifespan of critical components.

History & Background

The John Deere S685 was a significant addition to the S600 series combine harvesters. Introduced in the early 2010s, it offered increased capacity and efficiency compared to previous models. It represented John Deere's commitment to innovation in rotary combine technology.

Frequently Asked Questions

What engine is in the John Deere S685?

The John Deere S685 is powered by a John Deere PowerTech 9.0L diesel engine, producing approximately 431 horsepower and having a displacement of 549 cubic inches.

What is the grain tank capacity on a S685?

The grain tank capacity on the John Deere S685 is approximately 330 bushels, with an unloading rate of around 198 bushels per minute (3.3 bu/sec).

What type of separator does the S685 have?

The John Deere S685 utilizes a single rotor separator system, known for its high-capacity threshing and separating capabilities.

What are common parts needed for the S685?

Common parts needed for the John Deere S685 include concaves, rasp bars, belts (drive, header, feederhouse), chains (feederhouse, elevator), bearings (various locations), auger fingers, and sickle sections for the header.
