John Deere CTS-II Combine Parts
Browse John Deere Cts Ii Combine replacement parts. Everything from routine maintenance items to hard-to-find components.
The John Deere CTS II combine harvester, manufactured from 1994 to 1997, offered farmers a blend of performance and reliability. Powered by a robust engine delivering significant horsepower, it handled a wide range of header widths. Its unique combine threshing system combines conventional and rotary technologies. This model gained popularity for its efficient grain separation and reduced grain loss compared to older conventional models.
About the CTS II
The John Deere CTS II was produced from 1994 to 1997, filling a niche between traditional combines and the newer rotary models. It featured a Cummins 8.3L engine producing approximately 275 horsepower, providing ample power for demanding harvesting conditions. The CTS II utilized a unique hybrid separator system - an enhanced conventional cylinder for initial threshing followed by a pair of independent rotary separators for improved grain separation. Grain tank capacity was around 220 bushels, and it could unload at a rate of approximately 2.1 bushels per second or 126 bushels per minute. Available header widths ranged from 20 to 30 feet, accommodating various field sizes and crop types. It offered optional chopper and spreader attachments for residue management. The cab provided a comfortable operator environment, equipped with air conditioning and intuitive controls. The CTS II excelled in harvesting wheat, soybeans, and corn, due to its efficient threshing and separation system.
CTS II Specifications
| Engine | Cummins 8.3L 275 HP Diesel |
|---|---|
| Separator Type | Hybrid: Conventional Cylinder w/Twin Rotary Separators |
| Grain Tank | 220 bushels |
| Unloading Rate | 126 bu/min |
| Header Widths | 20-30 ft |
| Fuel Capacity | 150 gallons |
| Weight | Approximately 25,000 lbs |
| Years Produced | 1994-1997 |
CTS II Maintenance Tips
- Concave Adjustment: Regularly inspect and adjust concave clearance based on crop type and moisture content to optimize threshing performance and minimize grain damage.
- Belt and Chain Tension: Check and maintain proper tension on all belts and chains, ensuring smooth operation and preventing premature wear. Replace worn belts and chains promptly.
- Sieve and Chaffer Cleaning: Thoroughly clean sieves and chaffers to remove debris and ensure proper airflow for effective grain cleaning and separation.
- Bearing Greasing: Regularly grease all bearings according to the manufacturer's recommendations to prevent friction and extend bearing life.
CTS II History & Background
The John Deere CTS II was introduced in 1994 as a transitional model between conventional combines and the increasingly popular rotary designs. It represented a step towards improved grain separation efficiency. The CTS II combined a conventional cylinder for initial threshing with twin rotary separators to reduce grain loss and improve overall harvesting performance.
Frequently Asked Questions
What main bearing is used in the John Deere CTS II engine?
A standard main bearing for the John Deere CTS II engine is RE529319 - Main Bearing, Std..
Which concave insert is recommended for the John Deere CTS II?
For the John Deere CTS II, we recommend the AH206756 - Concave Insert - C/W Spring, Pin, Roll Pin & Washer.
Which cylinder spike tooth fits the John Deere CTS II?
The H132057 - Tooth, Cylinder Spike; w/ Hardware is a suitable replacement for the John Deere CTS II cylinder.
What common wear and maintenance parts are needed for the John Deere CTS II?
Key wear and maintenance items for the John Deere CTS II include a AH206756 - Concave Insert - C/W Spring, Pin, Roll Pin & Washer, H215004 - Blade, Straw Chopper, Stationary, VPK1551 - Hydraulic Filter, H133143 - Sprocket, Clean Grain Elevator, Lower, JD8665 - Bearing, and an RE62777 - Gasket, Exhaust Manifold; Outer (2/Pack).

RE520036 - Rear Crankshaft Seal
SKU: RE520036
236 in stock

RE65265 - Hand Primer
SKU: RE65265
176 in stock

RE62777 - Exhaust Manifold; Outer (2/Pack) Gasket
SKU: RE62777
896 in stock

RE62776 - Exhaust Manifold; Inner Gasket
SKU: RE62776
1106 in stock

RE61253 - Std. Thrust Washer Set
SKU: RE61253
10 in stock

RE57604 - Dual; Heavy Duty Torsional Damper
SKU: RE57604
Out of stock

RE57603 - Torsional Damper
SKU: RE57603
Out of stock

RE57054 - Camshaft W/ Tappets
SKU: RE57054
30 in stock

RE55475 - Head Gasket
SKU: RE55475
43 in stock

RE534314 - Crankshaft
SKU: RE534314
10 in stock

RE534183 - .011 Undersize Thrust Bearing
SKU: RE534183
Out of stock

RE534181 - .011 Undersize Main Bearing
SKU: RE534181
16 in stock

RE529320 - Std. Thrust Bearing
SKU: RE529320
440 in stock

RE529319 - Std. Main Bearing
SKU: RE529319
4392 in stock

RE527550 - Head Gasket Set
SKU: RE527550
7 in stock

RE527549 - Overhaul Gasket Set
SKU: RE527549
Out of stock

RE524105 - Oil Cooler To Block Gasket
SKU: RE524105
205 in stock

RE508156 - Low Compression Piston Piston Liner Kit
SKU: RE508156
69 in stock

RE507076 - Engine Oil Pump
SKU: RE507076
43 in stock

RE505265 - Roller Idler
SKU: RE505265
78 in stock

RE503528 - Piston Rings
SKU: RE503528
21 in stock

RE500934 - Torsional Damper
SKU: RE500934
20 in stock

RE40048 - Exhaust Clamp
SKU: RE40048
80 in stock

RE22764 - Rear Crankshaft Seal
SKU: RE22764
236 in stock
