Gleaner L2 Combine Parts

Jump to Parts

The Gleaner L2 combine, produced from 1972 to 1981, was known for its innovative sidehill self-leveling design and exceptional grain quality. Powered by a robust engine delivering around 165 HP, the L2 could handle a variety of header widths, typically ranging from 13 to 24 feet. Its conventional cylinder and walker separation system made it a favorite for farmers seeking a reliable and efficient harvesting solution.

The Gleaner L2 combine was introduced in 1972, representing an evolution of the Gleaner's commitment to efficient harvesting. Production continued through 1981. This model was typically powered by an Allis-Chalmers 426 cubic inch displacement diesel engine, producing approximately 165 horsepower. The L2 utilized a conventional threshing system with a 50-inch wide cylinder and four-walker separation system. Its grain tank held around 160 bushels, and the unloading auger had a discharge rate of approximately 40 bushels per minute. Available header widths ranged from 13 to 24 feet. Chopper and spreader options varied, allowing operators to customize residue management. The cab offered basic operator comfort and controls for adjusting threshing and cleaning settings. The Gleaner L2 excelled in harvesting a variety of grains, including wheat, soybeans, and corn, due to its gentle threshing action which minimized grain damage.

Specifications

Engine	Allis-Chalmers 426 CID 165 HP Diesel
Separator Type	Conventional - 50" Cylinder, 4 Walkers
Grain Tank	160 bushels
Unloading Rate	40 bu/min
Header Widths	13-24 ft
Fuel Capacity	75 gallons
Weight	18,000 lbs (approximate)
Years Produced	1972-1981

Maintenance Tips

Concave Adjustment: Regularly check and adjust concave clearance to ensure proper threshing without cracking grain. Refer to the operator's manual for recommended settings based on crop type.
Belt and Chain Tension: Inspect all belts and chains for proper tension and wear. Loose belts can slip, reducing efficiency, while worn chains can break. Replace worn components promptly.
Sieve and Chaffer Cleaning: Clean the sieves and chaffer regularly to remove debris and ensure proper airflow for efficient grain separation. This prevents grain loss and improves harvest quality.
Bearing Greasing: Lubricate all bearings according to the manufacturer's recommendations. Proper lubrication extends bearing life and prevents costly repairs.

History & Background

Introduced in 1972, the Gleaner L2 built upon the success of previous L series models, offering increased power and capacity. It represented a significant step forward in combine technology for Gleaner, known for its transverse-mounted engine and natural flow design. The L2 helped solidify Gleaner's reputation for producing combines that minimized grain damage and maximized harvesting efficiency.
