Ford New Holland 5030 Tractor Parts

5030 parts and accessories

The Ford New Holland 5030, manufactured from 1986 to 1999, was a popular utility tractor known for its reliability and versatility. Typically powered by a diesel engine producing around 62 horsepower, the 5030 delivered ample power for various farm tasks. Its robust PTO horsepower made it a favorite among farmers for operating implements like mowers and tillers, making it a workhorse on many farms.

The Ford New Holland 5030 was produced from 1986 to 1999, building upon the legacy of earlier Ford tractor models. It's primarily powered by a Shibaura diesel engine, typically producing around 62 horsepower. This engine, with a displacement around 179 cubic inches (2.9 liters), provided a good balance of power and fuel efficiency. The transmission options included a mechanical gear transmission with various speed configurations, usually an 8x2 or 12x4, offering flexibility for different applications. The 5030 boasts a PTO horsepower of approximately 53 HP, available at the standard 540 RPM. Its hydraulic system provides around 11 gallons per minute (GPM) flow, with typically two remote valves available for implement control. The 3-point hitch is typically a Category II, with a lift capacity around 3,000 lbs. Common farming applications included hay baling, mowing, light tillage, livestock feeding, and general utility work. The 5030 distinguished itself from other models in the Ford New Holland lineup with its slightly larger frame and higher horsepower compared to the smaller compact tractors, while remaining more economical and simpler than the larger row crop tractors.

Specifications

Engine	Shibaura 62 HP Diesel
PTO HP	53 HP @ 540 RPM
Transmission	Gear 8x2 or 12x4
Hydraulics	11 GPM, 2 remotes
3-Point Hitch	Category II, 3000 lbs
Fuel Capacity	17 gallons
Weight	5700 lbs
Years Produced	1986-1999

Maintenance Tips

Engine Oil and Filter: Change engine oil and filter every 250 hours using the recommended oil type and filter specification. Regularly check the oil level.
Hydraulic System: Inspect hydraulic fluid levels and filter condition every 500 hours. Change hydraulic fluid and filter per manufacturer's recommendations to prevent contamination and maintain hydraulic performance.
Fuel System: Use clean fuel and consider adding a fuel stabilizer, especially during seasonal storage. Drain the fuel sediment bowl regularly to remove water and contaminants.
Seasonal Storage: Before storing the tractor for the off-season, drain fluids that are exposed to water, grease all fittings, and store the battery in a cool, dry place. Consider covering the tractor to protect it from the elements.

History & Background

The Ford New Holland 5030 was introduced in 1986 as part of the Ford New Holland merger, combining the strengths of both brands. While the model remained relatively consistent throughout its production run, minor improvements were made to hydraulics and operator comfort. The 5030 became a staple on many farms due to its reliability and versatility during its production run.

Frequently Asked Questions

What engine is in the Ford New Holland 5030?

The Ford New Holland 5030 typically features a Shibaura 2.9L 3-cylinder diesel engine producing approximately 62 horsepower.

What is the PTO horsepower on a 5030?

The PTO horsepower on a Ford New Holland 5030 is approximately 53 HP, available at 540 RPM.

What oil filter fits the 5030?

Common oil filters for the 5030 include a Fram PH3600 or equivalent. Cross-reference with Wix 51348 or NAPA 1348 for other options. Verify filter specifications before installation.

What are common parts needed for the 5030?

Common wear parts for the 5030 include engine oil filters, fuel filters, air filters, hydraulic filters, fan belts, hydraulic pump seals, steering linkage components, clutch disc and pressure plate, and various O-rings and seals for hydraulic lines.
