Case IH MXM120 Tractor Parts

MXM120 parts and accessories

The Case IH MXM120 tractor, manufactured from 2003 to 2007, is a reliable workhorse for various farming applications. Powered by a 120 engine horsepower diesel engine, and boasting approximately 100 PTO horsepower, the MXM120 quickly became a favorite among farmers due to its robust design, comfortable cab, and versatile performance in the field. It offers a great balance of power and efficiency.

The Case IH MXM120 was produced between 2003 and 2007 and falls within the MXM series known for its blend of power and comfort. The MXM120 is equipped with a Case IH 6.7L 6-cylinder diesel engine, delivering approximately 120 engine horsepower. This engine provides ample power for a variety of tasks while maintaining good fuel efficiency. The transmission is typically a partial powershift, offering multiple forward and reverse speeds for precise control. PTO horsepower is around 100, with both 540 and 1000 RPM options available for compatibility with various implements. The hydraulic system offers a flow rate around 26 GPM, supporting multiple remote valves for hydraulic implements. It features a Category II 3-point hitch with a lift capacity around 6,945 lbs, making it suitable for row crop work, hay production, livestock operations, and light to medium tillage. What sets the MXM120 apart from other models in the lineup is its balanced power-to-weight ratio and comfortable operator environment, making it a versatile choice for many farming operations.

Specifications

Engine	Case IH 6.7L 120 HP Diesel
PTO HP	100 HP @ 540/1000 RPM
Transmission	Partial Powershift, 16F/16R
Hydraulics	26 GPM, 2-3 remotes
3-Point Hitch	Category II, 6,945 lbs
Fuel Capacity	47.6 gallons
Weight	12,125 lbs
Years Produced	2003-2007

Maintenance Tips

Engine Oil and Filter: Change the engine oil and filter every 250 hours using the recommended Case IH specification oil to ensure optimal engine performance and longevity.
Hydraulic System Maintenance: Regularly inspect hydraulic lines and fittings for leaks. Replace hydraulic filters every 500 hours to prevent contamination and maintain proper hydraulic function.
Fuel System Care: Use high-quality diesel fuel and check the fuel filter regularly. Drain water from the fuel tank periodically to prevent fuel system issues, especially during seasonal storage.
Seasonal Storage: Before storing the tractor for the off-season, stabilize the fuel, change the engine oil and filter, grease all fittings, and disconnect the battery. Store the tractor in a dry place to prevent corrosion.

History & Background

The Case IH MXM120 was introduced in 2003 as part of the MXM series, representing an evolution in tractor design and technology. While it didn't undergo major redesigns during its production run, it solidified Case IH's reputation for producing reliable and versatile mid-range tractors that catered to a broad range of farming needs.

Frequently Asked Questions

What engine is in the Case Ih MXM120?

The Case IH MXM120 is equipped with a Case IH 6.7L 6-cylinder diesel engine producing approximately 120 engine horsepower.

What is the PTO horsepower on a MXM120?

The PTO horsepower on a Case IH MXM120 is around 100 HP. It offers both 540 and 1000 RPM PTO speed options.

What oil filter fits the MXM120?

The correct oil filter for the MXM120 is typically a Case IH part number 87802231 or equivalent. Common cross-references include Wix 51794, Fleetguard LF3630, and Donaldson P551770.

What are common parts needed for the MXM120?

Commonly needed parts for the MXM120 include engine oil filters, fuel filters, hydraulic filters, air filters, belts (fan, alternator), hydraulic seals, steering components (tie rod ends, ball joints), clutch parts, and brake pads/discs.
