Case IH MAXXUM-125 Tractor Parts

MAXXUM 125 parts and accessories

The Case IH Maxxum 125 is a versatile agricultural tractor known for its reliability and performance in various farming applications. Manufactured from 2008-2015, it features a powerful FPT 6.7L diesel engine producing approximately 125 engine horsepower and around 105 PTO horsepower. Its robust design and advanced features made it a popular choice for farmers needing a capable and efficient machine.

The Case IH Maxxum 125 tractor was part of the Maxxum series, introduced to provide farmers with a range of horsepower options in a mid-size utility tractor. Production spanned from 2008 to 2015. The engine is an FPT (Fiat Powertrain Technologies) 6.7-liter, 6-cylinder diesel engine, delivering around 125 horsepower. The engine's high torque output made it suitable for demanding tasks. Several transmission options were available, including a standard 16x16 semi-powershift transmission and an optional 17x16 transmission with auto field shift. PTO horsepower is approximately 105 hp, with both 540 and 1000 RPM options available. The hydraulic system capacity is around 29 GPM, with multiple remote valves for implement control. The 3-point hitch is a Category II or III, offering a lift capacity of approximately 9,400 lbs. Commonly used for row crop work, hay production, livestock operations, and light tillage, the Maxxum 125 stood out for its comfortable cab, ease of operation, and versatility compared to smaller utility tractors and larger row-crop tractors.

Specifications

Engine	FPT 6.7L 125 HP Diesel
PTO HP	105 HP @ 540/1000 RPM
Transmission	Semi-Powershift 16x16
Hydraulics	29 GPM, 3 remotes
3-Point Hitch	Category II/III, 9400 lbs
Fuel Capacity	45 gallons
Weight	13,500 lbs
Years Produced	2008-2015

Maintenance Tips

Check and change the engine oil and filter every 250-300 hours using a high-quality oil that meets Case IH specifications.
Regularly inspect hydraulic fluid levels and change the hydraulic filter every 500 hours to prevent contamination and maintain optimal performance.
Use a fuel additive to prevent gelling during cold weather and inspect fuel filters regularly to ensure a clean fuel supply, as modern diesel engines are sensitive to fuel quality.
Before seasonal storage, ensure the fuel tank is full to prevent condensation, grease all lubrication points, and disconnect the battery to prevent drain.

History & Background

The Case IH Maxxum 125 was introduced in 2008 as part of the Maxxum series, offering a mid-range horsepower option for farmers. There were no major redesigns during its production run, making it a consistently reliable tractor in the Case IH lineup. Its popularity cemented the Maxxum name as a reliable workhorse in modern agriculture.

Frequently Asked Questions

What engine is in the Case Ih MAXXUM 125?

The Case IH Maxxum 125 is equipped with an FPT (Fiat Powertrain Technologies) 6.7-liter 6-cylinder diesel engine producing approximately 125 horsepower.

What is the PTO horsepower on a MAXXUM 125?

The PTO horsepower of the Case IH Maxxum 125 is approximately 105 horsepower. It offers both 540 and 1000 RPM PTO options.

What oil filter fits the MAXXUM 125?

The oil filter for the Case IH Maxxum 125 is typically a Case IH part number 84220521 or equivalent. Common cross-references include Baldwin B7349, Fleetguard LF9009, and Wix 57202.

What are common parts needed for the MAXXUM 125?

Common parts needed for the Case IH Maxxum 125 include engine oil filters, fuel filters (primary and secondary), hydraulic filters, air filters (inner and outer), belts, hydraulic seals, tie rod ends and other steering components, and clutch parts for models with a mechanical clutch.
