Case IH CX60 Tractor Parts

Jump to Parts

The Case IH CX60 was a popular utility tractor manufactured from 1998-2002. Powered by a robust 58 horsepower Iveco diesel engine, the CX60 offered excellent fuel efficiency and reliability. Its user-friendly design and approximately 50 PTO horsepower made it a favorite among farmers for a variety of tasks from mowing to loader work.

The Case IH CX60 was introduced in 1998 as part of the CX series, designed to provide a reliable and versatile utility tractor for small to medium-sized farms. Production continued until 2002. The heart of the CX60 is an Iveco 8035.05 3-cylinder diesel engine, delivering a rated 58 engine horsepower. This engine has a displacement of 2.9L (179 ci) and offers good torque for demanding tasks. The transmission is a synchro shift type with 12 forward and 12 reverse gears, providing a good range of speeds for various applications. The CX60 features a 540 RPM PTO, delivering around 50 PTO horsepower. The open-center hydraulic system provides approximately 11.6 GPM flow, sufficient for operating implements. It's a Category II 3-point hitch with a lift capacity of about 3,000 lbs. Common farming applications include hay baling, mowing, livestock feeding, light tillage, and loader work. The CX60 is distinguished from other models in the CX lineup by its specific engine horsepower and transmission options, offering a balanced combination of power and maneuverability.

Specifications

Engine	Iveco 8035.05 58 HP Diesel
PTO HP	50 HP @ 540 RPM
Transmission	Synchro Shift 12F/12R
Hydraulics	11.6 GPM, 2 remotes
3-Point Hitch	Category II, 3000 lbs
Fuel Capacity	17.2 gallons
Weight	5622 lbs
Years Produced	1998-2002

Maintenance Tips

Check the engine oil and filter every 250 hours. Use a high-quality oil that meets Case IH specifications. Always replace the filter when changing the oil.
Inspect hydraulic fluid levels and check for leaks regularly. Change the hydraulic fluid and filter every 1000 hours, or more frequently if operating in dusty conditions.
Use a fuel stabilizer during seasonal storage to prevent fuel degradation and keep the fuel system clean. Drain any water from the fuel filter/separator before extended storage.
Before each season, grease all lubrication points on the tractor, including steering linkage, loader pivots, and PTO shaft.

History & Background

The Case IH CX60 was introduced in 1998 as a member of the CX series, a line of utility tractors aimed at providing a versatile and reliable solution for a range of farm tasks. It saw no major redesigns during its production run. The CX60 played a role in providing smaller farms with a capable tractor option during the late 1990s and early 2000s.

Frequently Asked Questions

What engine is in the Case Ih CX60?

The Case IH CX60 is equipped with an Iveco 8035.05 3-cylinder diesel engine, producing 58 horsepower with a displacement of 2.9L (179 ci).

What is the PTO horsepower on a CX60?

The Case IH CX60 has a PTO horsepower rating of approximately 50 HP at 540 RPM.

What oil filter fits the CX60?

The oil filter for the Case IH CX60 is commonly a Fram PH2870A or equivalent. Other cross-references include Wix 51348 or a Case IH branded filter with the appropriate part number.

What are common parts needed for the CX60?

Common wear parts for the Case IH CX60 include engine oil filters, fuel filters, air filters, hydraulic filters, fan belts, hydraulic cylinder seal kits, tie rod ends, steering sector kits, and clutch discs/pressure plates.
