Case IH 9380 Tractor Parts

9380 parts and accessories

The Case IH 9380 was a powerful four-wheel drive tractor produced from 1991 to 1995. Powered by a robust 300 horsepower Cummins diesel engine, the 9380 delivered exceptional pulling power for demanding tasks. With a PTO horsepower rating of 240, it quickly became a favorite among farmers for its reliability and ability to handle large-scale tillage and planting operations.

The Case IH 9380 tractor was part of the 9300 series, which represented a significant step forward in four-wheel drive tractor technology for Case IH. Produced from 1991 to 1995, the 9380 was designed for large acreage farms requiring high horsepower and pulling capacity. Its Cummins N14 diesel engine, rated at 300 horsepower, provided ample power for heavy tillage, planting, and other demanding tasks. The engine displacement was 855 cubic inches. It used a 12-speed full powershift transmission. The PTO delivered 240 horsepower at 1000 RPM. Its hydraulic system had a flow rate of approximately 41 GPM, and was typically equipped with four remote valves. It was configured with a Category III/IVN 3-point hitch with a lift capacity of around 12,000 pounds. Common applications included primary tillage such as chisel plowing and disking, planting row crops like corn and soybeans, and pulling large grain carts during harvest. What distinguished the 9380 from other models in the Case IH lineup was its balanced combination of power, reliability, and operator comfort, making it a workhorse on many farms.

Specifications

Engine	Cummins N14 300 HP 855ci Diesel
PTO HP	240 HP @ 1000 RPM
Transmission	Full Powershift 12F/2R
Hydraulics	41 GPM, 4 remotes
3-Point Hitch	Category III/IVN, 12000 lbs
Fuel Capacity	170 gallons
Weight	25,480 lbs
Years Produced	1991-1995

Maintenance Tips

Engine Oil & Filter: Change the engine oil and filter every 250 hours using high-quality oil that meets Cummins specifications. Regularly check the oil level and ensure proper filtration to prevent engine wear.
Hydraulic System: Inspect hydraulic fluid levels and filters every 500 hours. Replace hydraulic filters and fluid per the manufacturer's recommendations to prevent contamination and maintain hydraulic system performance.
Fuel System: Use clean, high-quality diesel fuel and replace fuel filters regularly. Drain any water or sediment from the fuel tank to prevent fuel system issues.
Seasonal Storage: Before storing the tractor for the off-season, stabilize the fuel, change the engine oil and filter, lubricate all grease fittings, and protect the tires from direct sunlight. Consider using a battery maintainer to prevent battery discharge.

History & Background

The Case IH 9380 was introduced in 1991 as part of the 9300 series, replacing earlier models and representing an upgrade in horsepower and features. There were no major redesigns during its production run (1991-1995). The 9380 played a crucial role in enabling farmers to cover more ground efficiently, contributing to increased agricultural productivity.

Frequently Asked Questions

What engine is in the Case Ih 9380?

The Case IH 9380 is powered by a Cummins N14 inline 6-cylinder diesel engine, rated at 300 horsepower, with a displacement of 855 cubic inches.

What is the PTO horsepower on a 9380?

The PTO horsepower rating on the Case IH 9380 is 240 HP. The PTO operates at 1000 RPM.

What oil filter fits the 9380?

A common oil filter for the Case IH 9380 is a Fleetguard LF3349 or equivalent. Cross-references include Wix 51791 and Baldwin B1428. Always verify fitment with your parts supplier before ordering.

What are common parts needed for the 9380?

Commonly needed parts for the Case IH 9380 include: engine oil filters, fuel filters, air filters, hydraulic filters, fan belts, hydraulic cylinder seals, steering components (tie rod ends), and clutch discs/plates (though less frequent due to the powershift transmission).
