Case IH 9310 Tractor Parts

Jump to Parts

The Case IH 9310 tractor, manufactured from 1996 to 1999, was a robust and reliable workhorse for many farms. Powered by a Cummins M11 diesel engine producing around 275 horsepower, it delivered ample power for demanding tasks. Its impressive PTO horsepower, rated at approximately 225 HP, made it a popular choice for operating large implements and powering harvesting equipment.

The Case IH 9310 was part of the 9300 series tractors, produced from 1996 to 1999. These tractors aimed to provide high horsepower and advanced features for large-scale farming operations. At the heart of the 9310 lies a Cummins M11 inline 6-cylinder diesel engine, boasting a 661 cubic inch (10.8L) displacement and delivering approximately 275 horsepower. This engine offered excellent torque and fuel efficiency for its class. The tractor featured a robust 12-speed powershift transmission allowing for smooth gear changes under load. It had a PTO HP around 225 HP, available in 1000 RPM configuration. The hydraulic system offered a flow rate of around 32 GPM, with multiple remote valves for operating hydraulic implements. Its 3-point hitch was Category III, providing a lift capacity of approximately 9,700 lbs. Common applications for the Case IH 9310 included tillage, planting, row crop operations, and pulling large harvesting equipment. What distinguishes the 9310 from other models in the lineup was its specific horsepower rating and the blend of power and features it offered for its era.

Specifications

Engine	Cummins M11 275 HP 661 ci Diesel
PTO HP	225 HP @ 1000 RPM
Transmission	Powershift 12F/2R
Hydraulics	32 GPM, 3-4 remotes
3-Point Hitch	Category III, 9700 lbs
Fuel Capacity	150 gallons
Weight	24,000 lbs
Years Produced	1996-1999

Maintenance Tips

Engine Oil and Filter: Change the engine oil and filter every 250-300 hours using the recommended oil type (e.g., 15W-40) and a quality oil filter. Regularly inspect the oil level and condition.
Hydraulic System: Check the hydraulic oil level regularly and change the hydraulic filters every 500 hours. Use the specified hydraulic fluid and inspect hydraulic hoses and fittings for leaks or damage.
Fuel System: Use clean, high-quality diesel fuel and replace the fuel filters every 500 hours. Regularly drain any water or sediment from the fuel tank to prevent fuel system issues.
Seasonal Storage: Before storing the tractor for the off-season, drain the fuel tank or add a fuel stabilizer to prevent fuel degradation. Disconnect the battery and store it in a cool, dry place. Grease all lubrication points and inspect tires for proper inflation.

History & Background

The Case IH 9310 was introduced in 1996 as part of the 9300 series, representing Case IH's entry into the high-horsepower articulated tractor market. These tractors were significant for their robust design and powerful Cummins engines, becoming a staple in many large farming operations throughout the late 90s.

Frequently Asked Questions

What engine is in the Case Ih 9310?

The Case IH 9310 is powered by a Cummins M11 inline 6-cylinder diesel engine rated at approximately 275 horsepower with a 661 cubic inch (10.8L) displacement.

What is the PTO horsepower on a 9310?

The Case IH 9310 has a PTO horsepower rating of approximately 225 HP, operating at 1000 RPM.

What oil filter fits the 9310?

A common oil filter for the Case IH 9310 is a Fleetguard LF3349 or a Baldwin B1441. Always verify compatibility with your tractor's specific engine configuration.

What are common parts needed for the 9310?

Commonly needed parts for the Case IH 9310 include engine oil filters, fuel filters, hydraulic filters, air filters, belts (for the alternator and other accessories), hydraulic cylinder seal kits, steering cylinder seal kits, clutch components, and various bearings and bushings.
