Case IH 930 Tractor Parts

930 parts and accessories

The Case IH 930 tractor, manufactured from 1958 to 1969, was a popular choice among farmers for its reliability and versatility. Powered by a 76 horsepower engine, and delivering approximately 67 PTO horsepower, the 930 offered a robust platform for various agricultural tasks. Its dependable performance and straightforward design contributed to its enduring appeal.

The Case IH 930 tractor was produced from 1958 to 1969 and represented a significant step in tractor technology for its time. It was equipped with an International Harvester C-264 4-cylinder engine that delivered approximately 76 horsepower. This engine had a displacement of 264 cubic inches and was available in both diesel and gasoline configurations, depending on the year and market. The transmission was typically a 5-speed manual gear transmission, providing a suitable range of speeds for different farm operations. The PTO horsepower was around 67 HP, with a standard 540 RPM PTO. Hydraulic capacity was approximately 12 GPM, with typically 1 or 2 remote valves available. It featured a Category II 3-point hitch. Common farming applications included row crop work, hay baling, and general farm tasks. The 930 distinguished itself from other models with its balance of power and ease of maintenance, appealing to a wide range of farmers.

Specifications

Engine	International Harvester C-264 76 HP 264 ci Diesel/Gas
PTO HP	67 HP @ 540 RPM
Transmission	Gear 5-speed
Hydraulics	12 GPM, 1-2 remotes
3-Point Hitch	Category II, 3200 lbs Lift Capacity
Fuel Capacity	28 gallons
Weight	6300 lbs
Years Produced	1958-1969

Maintenance Tips

Change engine oil and filter every 100-150 hours of operation using a high-quality oil that meets the manufacturer's specifications. Always replace the oil filter with a new, compatible filter.
Inspect hydraulic fluid levels regularly and change the hydraulic filter every 250-300 hours. Use the correct type of hydraulic fluid recommended for the 930's system.
Keep the fuel system clean by using fuel stabilizers, especially during seasonal storage, to prevent fuel degradation and clogging of fuel filters and injectors. Drain any water accumulation.
Before storing the tractor for the off-season, perform a thorough inspection, lubricate all grease fittings, and protect exposed metal surfaces with a rust inhibitor.

History & Background

Introduced in 1958, the Case IH 930 filled a crucial role in the company's tractor lineup, offering a mid-range power option for farmers. While there weren't major redesigns during its production run, refinements were made to improve performance and reliability. The 930 is remembered for its sturdy build and contribution to the advancement of farming practices.

Frequently Asked Questions

What engine is in the Case Ih 930?

The Case IH 930 is equipped with an International Harvester C-264 engine, producing approximately 76 horsepower. It has a displacement of 264 cubic inches and was available in both diesel and gasoline versions.

What is the PTO horsepower on a 930?

The PTO horsepower on a Case IH 930 is approximately 67 HP, operating at 540 RPM.

What oil filter fits the 930?

Common oil filters for the Case IH 930 include Wix 51250, Fram PH5, and equivalent replacements. Always verify compatibility with your specific engine configuration.

What are common parts needed for the 930?

Common parts needed for the Case IH 930 include oil filters, fuel filters, hydraulic filters, belts (fan, alternator), hydraulic seals for cylinders and pumps, steering components (tie rod ends, ball joints), and clutch parts (disc, pressure plate, throwout bearing).
