Case IH 9210 Tractor Parts

9210 parts and accessories

The Case IH 9210 tractor, manufactured from 1994 to 1997, was a popular choice for farmers needing reliable power. Powered by a Cummins 8.3L diesel engine producing approximately 175 engine HP and delivering around 145 PTO HP, it offered a good balance of performance and fuel efficiency. Farmers appreciated its robust design and versatile capabilities for various field tasks.

The Case IH 9210 was part of the 9000 series tractors produced by Case IH from 1994 to 1997. This series was designed to provide farmers with reliable and powerful machines for a variety of agricultural applications. The 9210 is equipped with a Cummins 8.3L inline 6-cylinder diesel engine, delivering approximately 175 horsepower. The engine's displacement is 505 cubic inches. It features a powershift transmission with 18 forward and 4 reverse gears, providing a wide range of speeds for different field conditions. The PTO horsepower is around 145 HP, with both 540 and 1000 RPM PTO options available. The hydraulic system has a capacity of approximately 30 gallons per minute and typically features 3 remote valves. The 3-point hitch is a Category II or III, with a lift capacity of around 8,750 lbs. The 9210 was commonly used in row crop farming, hay production, livestock operations, and tillage work. Compared to other models in the 9000 series, the 9210 offered a mid-range horsepower option, providing a balance between power and maneuverability.

Specifications

Engine	Cummins 8.3L 175 HP Diesel
PTO HP	145 HP @ 540/1000 RPM
Transmission	Powershift 18F/4R
Hydraulics	30 GPM, 3 remotes
3-Point Hitch	Category II/III, 8750 lbs
Fuel Capacity	75 gallons
Weight	16,500 lbs
Years Produced	1994-1997

Maintenance Tips

Engine Oil & Filter: Change the engine oil and filter every 250-300 hours of operation. Use a high-quality oil that meets Case IH specifications.
Hydraulic System: Check hydraulic fluid levels regularly and change the hydraulic filter every 500 hours. Inspect hoses and fittings for leaks.
Fuel System: Use clean, high-quality diesel fuel. Replace the fuel filter every 500 hours to prevent fuel system contamination.
Seasonal Storage: Before storing the tractor for the off-season, fill the fuel tank to prevent condensation, change the engine oil and filter, and grease all lubrication points.

History & Background

Introduced in 1994, the Case IH 9210 was part of the 9000 series that aimed to deliver enhanced power and improved operator comfort compared to previous models. There were no major redesigns during its production run. The 9210 contributed to Case IH's reputation for producing dependable and versatile agricultural tractors.

Frequently Asked Questions

What engine is in the Case Ih 9210?

The Case IH 9210 is powered by a Cummins 8.3L inline 6-cylinder diesel engine producing approximately 175 horsepower.

What is the PTO horsepower on a 9210?

The PTO horsepower on the Case IH 9210 is around 145 HP, and it offers both 540 and 1000 RPM PTO options.

What oil filter fits the 9210?

The Case IH 9210 typically uses a Fleetguard LF3349 or a Baldwin B1410 oil filter. Cross-references include Wix 51791 and NAPA 1791.

What are common parts needed for the 9210?

Common parts needed for the Case IH 9210 include engine oil filters, fuel filters, hydraulic filters, belts, hydraulic cylinder seals, steering components, and clutch parts.
