Case IH 886 Tractor Parts

886 parts and accessories

The Case IH 886 tractor, manufactured from 1976 to 1980, was a popular choice for farmers needing a versatile machine for various tasks. Powered by an International Harvester D-358 diesel engine producing around 86 horsepower, the 886 offered a reliable workhorse solution. Its 72 PTO horsepower made it well-suited for operating a range of implements, contributing to its reputation as a dependable tractor.

The Case IH 886 was introduced as part of the '86 Series,' known for their improved operator comfort and hydraulic performance compared to previous models. Production ran from 1976 to 1980. The heart of the 886 is an International Harvester D-358 6-cylinder diesel engine with a 358 cubic inch (5.9L) displacement, delivering approximately 86 engine horsepower. A gasoline version was not offered. The standard transmission was a gear-type with 8 forward and 4 reverse speeds. The independent PTO delivers around 72 horsepower at 540 RPM. The hydraulic system has a capacity of approximately 15 GPM, powering two remote valves. The 3-point hitch is a Category II, providing a lift capacity of around 4,400 lbs. Common applications included row crop work, hay production, livestock operations, and light tillage. The 886 stood out for its comfortable cab (optional), improved hydraulics, and its robust engine, differentiating it from smaller frame tractors while remaining more economical than larger models.

Specifications

Engine	International Harvester D-358 86 HP Diesel
PTO HP	72 HP @ 540 RPM
Transmission	Gear 8F/4R
Hydraulics	15 GPM, 2 remotes
3-Point Hitch	Category II, 4400 lbs
Fuel Capacity	33 gallons
Weight	7,484 lbs
Years Produced	1976-1980

Maintenance Tips

Engine Oil & Filter: Change the engine oil and filter every 250 hours using a high-quality diesel engine oil that meets or exceeds the manufacturer's specifications. Regularly check the oil level and condition.
Hydraulic Maintenance: Inspect hydraulic lines and fittings for leaks regularly. Change the hydraulic fluid and filter according to the manufacturer's recommendations (typically every 500-1000 hours) to ensure proper system performance and prevent contamination.
Fuel System Care: Use clean, high-quality diesel fuel. Replace the fuel filter every 250 hours to prevent fuel system clogs and ensure optimal engine performance. Consider using a fuel additive to prevent gelling in cold weather.
Seasonal Storage: Before storing the tractor for an extended period, stabilize the fuel, change the engine oil and filter, lubricate all grease fittings, and disconnect the battery. Store the tractor in a dry, sheltered location.

History & Background

The Case IH 886 was launched in 1976 as a mid-sized utility tractor within the International Harvester '86 Series. This series marked a significant step forward in operator comfort and hydraulic performance. The 886 became a popular model for its versatility and reliability on farms of various sizes.

Frequently Asked Questions

What engine is in the Case Ih 886?

The Case IH 886 is equipped with an International Harvester D-358 6-cylinder diesel engine, producing approximately 86 horsepower with a 358 cubic inch displacement.

What is the PTO horsepower on a 886?

The Case IH 886 has a PTO horsepower rating of approximately 72 horsepower at 540 RPM. It's an independent PTO.

What oil filter fits the 886?

The common oil filter for the Case IH 886 is a Fram PH2951, Wix 51794, or a Case IH part number 3132617R1. Always verify fitment with your tractor's serial number.

What are common parts needed for the 886?

Common parts needed for the Case IH 886 include: fuel filters, oil filters, air filters, hydraulic filters, fan belts, radiator hoses, hydraulic pump seals, tie rod ends, steering cylinder repair kits, clutch discs, and pressure plates.
