Case IH 6788 Tractor Parts

6788 parts and accessories

The Case IH 6788 tractor, manufactured from 1988 to 1993, was a popular choice for farmers needing a reliable and powerful machine. Powered by a 160 horsepower diesel engine, this tractor delivered impressive performance in the field. With a PTO horsepower of 135, the 6788 was well-suited for a variety of implements and tasks, making it a versatile workhorse.

The Case IH 6788 was introduced in 1988 as part of the Magnum series, building on the legacy of its predecessors while incorporating updated features and improved performance. Production continued until 1993. The 6788 is powered by a Case IH 6-cylinder diesel engine, producing approximately 160 horsepower with a displacement of around 402 cubic inches. It features a robust powershift transmission offering smooth gear changes for enhanced efficiency. The PTO delivers around 135 horsepower, with both 540 and 1000 RPM options available to accommodate different implements. Hydraulic capacity is substantial, providing sufficient flow for demanding hydraulic functions, typically around 30 GPM with multiple remote valves. Equipped with a Category II 3-point hitch, the 6788 handles a wide range of implements for row crop farming, hay production, and tillage applications. What set the 6788 apart from other tractors in its class was its blend of power, reliability, and operator comfort, making it a favorite among farmers looking for a dependable machine for diverse farming operations.

Specifications

Engine	Case IH 6-Cylinder 160 HP Diesel
PTO HP	135 HP @ 540/1000 RPM
Transmission	Powershift, 18 Forward / 9 Reverse
Hydraulics	30 GPM, 3 remotes
3-Point Hitch	Category II, 6750 lbs lift capacity
Fuel Capacity	80 gallons
Weight	15,500 lbs
Years Produced	1988-1993

Maintenance Tips

Change engine oil and filter every 250 hours using a high-quality oil that meets Case IH specifications.
Regularly inspect and clean the hydraulic system, changing the hydraulic fluid and filters according to the manufacturer's recommendations to prevent contamination and maintain performance.
Check and maintain the fuel system, ensuring clean fuel and replacing fuel filters regularly to prevent engine problems.
When storing the tractor for extended periods, drain the fuel tank or add a fuel stabilizer to prevent fuel degradation and protect the fuel system.

History & Background

The Case IH 6788 was introduced in 1988 as part of the Magnum series, representing a significant step forward in tractor design and technology. While maintaining the core principles of reliability and performance, the 6788 incorporated improvements in operator comfort and efficiency. Its introduction solidified Case IH's position as a leader in the agricultural machinery market.

Frequently Asked Questions

What engine is in the Case Ih 6788?

The Case IH 6788 is equipped with a Case IH 6-cylinder diesel engine, producing approximately 160 horsepower with a displacement of around 402 cubic inches.

What is the PTO horsepower on a 6788?

The Case IH 6788 has a PTO horsepower rating of approximately 135 HP. It typically offers both 540 and 1000 RPM PTO speed options.

What oil filter fits the 6788?

Common oil filters for the Case IH 6788 include Fleetguard LF3349, Wix 51794, or Case IH part number J932249. Always verify the correct fit with your parts supplier.

What are common parts needed for the 6788?

Common wear parts for the Case IH 6788 include engine oil filters, fuel filters, hydraulic filters, belts, hydraulic seals, steering components, clutch parts, and tires.
