Case IH 6388 Tractor Parts

6388 parts and accessories

The Case IH 6388 tractor, produced from 1994 to 1996, was a popular choice for farmers needing a reliable and powerful machine. Powered by a 160 horsepower Cummins 5.9L diesel engine and offering around 135 PTO horsepower, this tractor was well-suited for a variety of agricultural tasks. Its robust design and versatile capabilities made it a workhorse on many farms.

The Case IH 6388 tractor was manufactured between 1994 and 1996, filling a crucial role in the Case IH lineup for mid-sized farming operations. It's powered by a Cummins 5.9L inline 6-cylinder diesel engine, producing approximately 160 horsepower. This engine has a displacement of 359 cubic inches. The 6388 features a partial powershift transmission, with options including 18 forward and 6 reverse gears, providing excellent control for field work. Its PTO delivers around 135 horsepower, available in both 540 and 1000 RPM configurations. The hydraulic system offers a flow rate of approximately 25 GPM, with the option for multiple remote valves. The 3-point hitch is a Category II, offering a lift capacity around 6,700 lbs. Common applications for the 6388 include row crop work, hay production, livestock operations, and light to medium tillage. It distinguished itself with a blend of power, reliability, and electronic controls that allowed for very precise implement management compared to the earlier tractors in its class.

Specifications

Engine	Cummins 5.9L 160 HP Diesel
PTO HP	135 HP @ 540/1000 RPM
Transmission	Partial Powershift, 18F/6R
Hydraulics	25 GPM, 2-3 remotes
3-Point Hitch	Category II, 6700 lbs
Fuel Capacity	68 gallons
Weight	14,500 lbs
Years Produced	1994-1996

Maintenance Tips

Change the engine oil and filter every 250 hours of operation using a high-quality oil specified for diesel engines.
Regularly inspect and maintain the hydraulic system, checking for leaks and ensuring the fluid is clean and at the proper level. Change hydraulic filters according to the manufacturer's recommendations.
Use only clean, high-quality fuel and consider using a fuel additive to prevent gelling in cold weather. Replace fuel filters regularly to maintain optimal engine performance.
Before storing the tractor for the off-season, drain the fuel tank or add a fuel stabilizer to prevent fuel degradation. Also, grease all fittings and protect the tires from prolonged exposure to sunlight.

History & Background

The Case IH 6388 was introduced in 1994 as part of the Maxxum series, offering a modern blend of power and electronic controls. It did not undergo any major redesigns during its short production run. This model was significant for providing operators with improved comfort, efficiency, and precision in various farming tasks.

Frequently Asked Questions

What engine is in the Case Ih 6388?

The Case IH 6388 is equipped with a Cummins 5.9L inline 6-cylinder diesel engine producing approximately 160 horsepower with 359 cubic inch displacement.

What is the PTO horsepower on a 6388?

The Case IH 6388 has a PTO horsepower rating of approximately 135 HP and offers both 540 and 1000 RPM PTO speeds.

What oil filter fits the 6388?

The Case IH 6388 typically uses a Fleetguard LF3349 or a Baldwin B1441 oil filter. Cross-references include Wix 51791 and NAPA 1791.

What are common parts needed for the 6388?

Common parts needed for the Case IH 6388 include engine oil filters, fuel filters, air filters, hydraulic filters, belts, hydraulic cylinder seal kits, steering components (tie rod ends, ball joints), and clutch components. Radiator hoses, thermostats, and water pumps are also commonly replaced maintenance items.
