Case IH 584 Tractor Parts

584 parts and accessories

The Case IH 584 tractor, manufactured from 1975 to 1984, was a popular choice for farmers due to its reliable performance and versatility. Powered by a robust 54 horsepower diesel engine and offering approximately 48 PTO horsepower, this tractor was well-suited for various agricultural tasks. Its straightforward design and dependable operation made it a workhorse on many farms.

The Case IH 584 was introduced in 1975 as part of the International Harvester (later Case IH) utility tractor lineup. Production continued until 1984. This model was designed to provide a balance of power, maneuverability, and affordability for small to medium-sized farms. The 584 is powered by an International Harvester D-239 4-cylinder diesel engine, producing approximately 54 engine horsepower. The engine has a displacement of 239 cubic inches. A gasoline engine option was also available, but less common. Transmission options typically included a gear-type transmission with varying speeds, often an 8-speed forward, 2-speed reverse setup. The PTO delivers approximately 48 horsepower and is typically a 540 RPM PTO. Hydraulic capacity is around 7.5 GPM, often with one or two remote valves available. The 3-point hitch is typically Category II, providing a lift capacity around 3500 lbs. Common applications for the 584 include row crop work, haying operations, livestock feeding, and light tillage. What distinguishes the 584 from other tractors in the Case IH line is its combination of a relatively small footprint with sufficient power for a wide array of tasks, making it a versatile all-around tractor.

Specifications

Engine	International Harvester D-239 54 HP Diesel
PTO HP	48 HP @ 540 RPM
Transmission	Gear, 8 Forward/2 Reverse
Hydraulics	7.5 GPM, 1-2 remotes
3-Point Hitch	Category II, 3500 lbs
Fuel Capacity	17 gallons
Weight	5500 lbs
Years Produced	1975-1984

Maintenance Tips

Change engine oil and filter every 250 hours of operation, using the recommended oil type for diesel engines.
Inspect and maintain hydraulic fluid levels regularly, checking for leaks and replacing filters according to the manufacturer's recommendations.
Use a fuel stabilizer during seasonal storage to prevent fuel degradation and ensure easy starting next season. Clean or replace fuel filters annually.
Periodically inspect and lubricate all grease fittings on the tractor, including steering components, PTO shaft, and hitch linkages.

History & Background

The Case IH 584 was launched in 1975, representing International Harvester's effort to provide a reliable and economical tractor for diverse farming operations. While the model didn't undergo major redesigns during its production run, it benefited from continuous improvements in manufacturing and component quality. The 584 remains a respected and sought-after tractor for its simplicity, durability, and ease of maintenance.

Frequently Asked Questions

What engine is in the Case Ih 584?

The Case IH 584 is typically equipped with an International Harvester D-239 4-cylinder diesel engine, producing approximately 54 horsepower.

What is the PTO horsepower on a 584?

The PTO horsepower on the Case IH 584 is approximately 48 HP at 540 RPM.

What oil filter fits the 584?

Common oil filter cross-references for the Case IH 584 include Fram PH2870A, Wix 51258, and NAPA 1258. Always verify the correct filter for your specific engine configuration.

What are common parts needed for the 584?

Common parts frequently needed for the Case IH 584 include oil filters, fuel filters, air filters, hydraulic filters, belts, hydraulic cylinder seal kits, steering components (tie rod ends, drag links), and clutch components (disc, pressure plate, release bearing).
