Case IH 560 Tractor Parts

560 parts and accessories

The Case IH 560 tractor, manufactured from 1958 to 1963, was a workhorse on American farms. Powered by either a gasoline or diesel engine producing around 58 horsepower, with a PTO HP of approximately 52, it gained popularity for its reliable performance and versatility. Farmers appreciated its ability to handle a variety of tasks from plowing to planting.

The Case IH 560 was introduced in 1958 as part of International Harvester's (later Case IH) lineup of utility tractors. Production continued until 1963, solidifying its place as a dependable machine for small to medium-sized farms. It was available with either a gasoline or diesel engine option. The gasoline engine was an International Harvester C-264 with approximately 58 HP and 264 cubic inch displacement. The diesel engine was an International Harvester D-282 with approximately 55 HP and 282 cubic inch displacement. Both were naturally aspirated. It featured a standard 5-speed manual transmission, with optional Torque Amplifier, providing increased versatility in the field. The independent PTO delivered around 52 HP at 540 RPM. The hydraulic system had a capacity of approximately 8 GPM, powering a category II 3-point hitch. The 560 was commonly used for row crop work, hay baling, and general farm tasks. What distinguished the 560 from other models was its improved hydraulic system and more powerful engine compared to smaller tractors, while remaining compact and maneuverable.

Specifications

Engine	International Harvester C-264 58 HP Gasoline / D-282 55 HP Diesel
PTO HP	52 HP @ 540 RPM
Transmission	5-Speed Manual, Optional Torque Amplifier
Hydraulics	8 GPM, 1-2 remotes
3-Point Hitch	Category II, 3000 lbs lift capacity
Fuel Capacity	25 gallons
Weight	5200 lbs
Years Produced	1958-1963

Maintenance Tips

Change the engine oil and filter every 125 hours of operation using a high-quality oil designed for agricultural diesel/gas engines.
Regularly check and maintain the hydraulic system, including fluid levels and filter changes, to prevent costly repairs.
Inspect the fuel system for leaks and replace fuel filters regularly to ensure clean fuel delivery and optimal engine performance.
Before seasonal storage, drain fluids, grease all fittings, and protect tires from direct sunlight to prevent deterioration.

History & Background

The Case IH 560 was introduced in 1958 as a successor to earlier IH tractor models. It represented a step up in power and features compared to its predecessors, offering farmers a more capable machine for a wider range of tasks. Its success helped solidify International Harvester's position as a leading agricultural equipment manufacturer.

Frequently Asked Questions

What engine is in the Case Ih 560?

The Case IH 560 could be equipped with either the International Harvester C-264 gasoline engine rated at approximately 58 horsepower or the International Harvester D-282 diesel engine, rated at approximately 55 horsepower.

What is the PTO horsepower on a 560?

The PTO horsepower for the Case IH 560 is approximately 52 horsepower delivered at 540 RPM.

What oil filter fits the 560?

For the Case IH 560 with the gas engine, a common oil filter is a Wix 51060 or a Fram PH8A. For the diesel engine, use Wix 51794 or Fram PH1144. Always verify with your parts supplier for the most accurate cross-reference.

What are common parts needed for the 560?

Commonly needed parts for the Case IH 560 include: engine oil filters, fuel filters, hydraulic filters, fan belts, radiator hoses, steering components (tie rod ends, drag links), clutch discs and pressure plates, and hydraulic pump seals.
