Case IH 5220 Tractor Parts

5220 parts and accessories

The Case IH 5220 tractor, manufactured from 1991 to 1996, was a popular choice for farmers needing a versatile utility tractor. Powered by a reliable 82 horsepower diesel engine, and boasting a 68 PTO horsepower, the 5220 excelled in a variety of agricultural applications. Its robust design and user-friendly operation made it a workhorse on farms across the country.

The Case IH 5220 was part of the popular 5100/5200 series, produced between 1991 and 1996. It's powered by a Case IH 4-390 4-cylinder diesel engine producing approximately 82 engine horsepower. The engine has a displacement of 239 cubic inches (3.9L). These tractors came equipped with a standard mechanical transmission, offering options like a synchro shift with 16 forward and 8 reverse gears. The PTO delivers approximately 68 horsepower, with a standard 540 RPM PTO. Hydraulic capacity is rated around 12.3 GPM powering 2 rear remotes. The 3-point hitch is a Category II, offering a lift capacity of around 4,750 lbs. Farmers commonly used the 5220 for row crop work like planting and cultivating, hay baling, livestock feeding, and light tillage operations. What distinguishes the 5220 from other models in the lineup is its balance of power, relatively compact size, and dependable performance, making it a suitable tractor for small to medium-sized farms.

Specifications

Engine	Case IH 4-390 82 HP Diesel
PTO HP	68 HP @ 540 RPM
Transmission	Mechanical Synchroshift, 16F/8R
Hydraulics	12.3 GPM, 2 remotes
3-Point Hitch	Category II, 4750 lbs
Fuel Capacity	27 gallons
Weight	7,700 lbs
Years Produced	1991-1996

Maintenance Tips

Engine Oil & Filter: Change your engine oil and filter every 250 hours of operation using the recommended Case IH spec oil (typically 15W-40) to maximize engine life. Be sure to use a high-quality filter designed for diesel engines.
Hydraulic System: Regularly check hydraulic fluid levels and inspect for leaks. Change the hydraulic fluid and filter every 500 hours, or more frequently if operating in dusty conditions, to prevent damage to hydraulic components.
Fuel System: Use clean, high-quality diesel fuel and add a fuel stabilizer during seasonal storage. Inspect the fuel filter regularly and replace it every 250 hours to prevent fuel system issues.
Seasonal Storage: Before storing the tractor for extended periods, drain the fuel tank, add fuel stabilizer to prevent gelling, and disconnect the battery. Store the tractor in a dry, covered location to protect it from the elements.

History & Background

The Case IH 5220 was introduced in 1991 as part of the 5100/5200 series, representing an evolution of Case IH's utility tractor offerings. There were no major redesigns during its production run, solidifying its place as a reliable and practical tractor in a time when farms were looking for efficient and versatile equipment.

Frequently Asked Questions

What engine is in the Case Ih 5220?

The Case IH 5220 is powered by a Case IH 4-390 4-cylinder diesel engine, producing around 82 horsepower.

What is the PTO horsepower on a 5220?

The PTO horsepower on the Case IH 5220 is approximately 68 horsepower, operating at 540 RPM.

What oil filter fits the 5220?

The common oil filter for the Case IH 5220 is a Baldwin B1421, Fleetguard LF3349, or equivalent.

What are common parts needed for the 5220?

Common wear parts include engine oil filters, fuel filters, hydraulic filters, belts (fan, alternator), hydraulic seals, steering components (tie rod ends), and clutch disc/pressure plate parts. Regular inspection and replacement of these parts will ensure reliable operation.
