Case IH 5140 Tractor Parts

5140 parts and accessories

The Case IH 5140 tractor, manufactured from 1990 to 1996, was a reliable workhorse on farms across North America. Powered by a robust 95 horsepower diesel engine and boasting a PTO horsepower of around 80, the 5140 became popular with farmers because of its balance of power, versatility, and comfortable cab. It offered a perfect blend of modern features and practical design.

The Case IH 5140 was part of the Maxxum series, introduced in the early 1990s to provide farmers with a mid-size tractor offering increased comfort and productivity. It was produced from 1990 to 1996. Under the hood, you'll find a Case IH 6-cylinder diesel engine, rated at approximately 95 horsepower with a displacement of around 359 cubic inches. The engine provided ample power for a variety of tasks. The transmission options included a standard synchronized gear transmission with multiple speeds or a partial powershift option for easier shifting on the go. The PTO horsepower was typically around 80, offering both 540 and 1000 RPM options. Hydraulics provided around 20 GPM of flow, operating two or more remote valves. The 3-point hitch was a Category II, capable of lifting approximately 6,800 lbs. The 5140 found use in various applications, including row crop operations, hay making, livestock feeding, and light tillage. Compared to other Maxxum models, the 5140 offered a balance of power and size, making it a sweet spot for many farmers seeking a dependable and versatile tractor.

Specifications

Engine	Case IH 95 HP Diesel, 359 ci
PTO HP	80 HP @ 540/1000 RPM
Transmission	Gear or Partial Powershift, Multiple Speeds
Hydraulics	20 GPM, 2-3 remotes
3-Point Hitch	Category II, 6,800 lbs Lift Capacity
Fuel Capacity	34 gallons
Weight	9,800 lbs
Years Produced	1990-1996

Maintenance Tips

Change engine oil and filter every 250 hours using high-quality oil meeting Case IH specifications.
Regularly inspect hydraulic fluid levels and filter condition. Replace hydraulic filters as recommended to prevent contamination.
Use clean, high-quality diesel fuel and maintain the fuel filter to avoid fuel system issues. Drain water from the fuel tank regularly.
Before seasonal storage, completely fill the fuel tank, add a fuel stabilizer, and grease all lubrication points to prevent corrosion and ensure smooth operation next season.

History & Background

The Case IH 5140 was launched in 1990 as part of the Maxxum series, designed to offer improved operator comfort and enhanced features compared to earlier Case IH models. There were no major redesigns during its production run, cementing its place as a reliable and practical tractor, and it represents a significant step in tractor design, bridging the gap between older mechanical tractors and more modern electronic models.

Frequently Asked Questions

What engine is in the Case Ih 5140?

The Case IH 5140 is equipped with a Case IH 6-cylinder diesel engine, producing approximately 95 horsepower and a displacement of around 359 cubic inches.

What is the PTO horsepower on a 5140?

The PTO horsepower on the Case IH 5140 is approximately 80 horsepower, with options for both 540 and 1000 RPM PTO speeds.

What oil filter fits the 5140?

The Case IH 5140 typically uses a Fram PH3600 or equivalent oil filter. Other common cross-references include Wix 51794 and Baldwin B233.

What are common parts needed for the 5140?

Common parts needed for the Case IH 5140 include engine oil filters, fuel filters, hydraulic filters, fan belts, hydraulic seals (especially for cylinders and remotes), steering components (tie rod ends), and clutch components (discs, pressure plates).

Showing 193-216 of 360 products

Sort by:
