Case IH 5088 Tractor Parts

5088 parts and accessories

The Case IH 5088 tractor, manufactured from 2010 to 2013, is a workhorse for modern farming operations. Powered by a robust 6.7L FPT diesel engine producing around 125 horsepower, the 5088 delivers a PTO horsepower of approximately 100 hp. This tractor gained popularity among farmers for its balance of power, reliability, and advanced technology, making it suitable for a variety of field tasks.

The Case IH 5088 was introduced as part of the Farmall series, designed to offer enhanced performance and operator comfort. Production years spanned from 2010 to 2013. The heart of the 5088 is an FPT (Fiat Powertrain Technologies) 6.7-liter 6-cylinder diesel engine, delivering a rated engine power of approximately 125 horsepower. This engine is known for its fuel efficiency and durability. The tractor features a partial powershift transmission, offering multiple speeds forward and reverse (typically 18x6), providing flexibility for various field conditions. The independent PTO delivers around 100 horsepower, switchable between 540 and 1000 RPM, catering to a wide range of implements. The hydraulic system has a capacity of around 26 GPM, supporting implements with up to 3 rear remotes. The 3-point hitch is a Category II, offering a lift capacity of approximately 7,165 lbs. The Case IH 5088 is commonly used for row crop operations, hay production, livestock management, and light tillage work. It stands out from smaller utility tractors by offering more power and advanced features, and from larger models by being more agile and fuel-efficient for smaller farms.

Specifications

Engine	FPT 6.7L 125 HP Diesel
PTO HP	100 HP @ 540/1000 RPM
Transmission	Partial Powershift 18x6
Hydraulics	26 GPM, Up to 3 remotes
3-Point Hitch	Category II, 7,165 lbs lift capacity
Fuel Capacity	40 gallons
Weight	12,500 lbs
Years Produced	2010-2013

Maintenance Tips

Engine Oil & Filter: Change the engine oil and filter every 250 hours of operation using the recommended Case IH oil specification to ensure optimal engine performance and longevity.
Hydraulic System: Check hydraulic fluid levels regularly and replace the hydraulic filter every 500 hours or annually, whichever comes first. Use Case IH Hy-Tran fluid to prevent contamination and maintain hydraulic system efficiency.
Fuel System: Use clean, high-quality diesel fuel and regularly check the fuel filter for any signs of clogging. Drain any water accumulated in the fuel/water separator to prevent fuel system issues.
Seasonal Storage: Before storing the tractor for the off-season, fill the fuel tank to prevent condensation, change the engine oil, grease all fittings, and disconnect the battery. Consider using a fuel stabilizer to prevent fuel degradation during storage.

History & Background

The Case IH 5088 was part of the Farmall series update, bringing modern technology and improved comfort to the popular Farmall line. While not a radical redesign, it represented a significant step forward in terms of engine efficiency and transmission options. The 5088 played a crucial role in providing mid-sized farms with a reliable and versatile tractor.

Frequently Asked Questions

What engine is in the Case Ih 5088?

The Case IH 5088 is powered by an FPT (Fiat Powertrain Technologies) 6.7-liter 6-cylinder diesel engine, producing approximately 125 horsepower.

What is the PTO horsepower on a 5088?

The Case IH 5088 has a PTO horsepower rating of approximately 100 HP, with options for both 540 and 1000 RPM PTO speeds.

What oil filter fits the 5088?

The oil filter for the Case IH 5088 is typically a Case IH part number 84220751 or equivalent. Common cross-references include Wix 57004, Fleetguard LF9009, and Baldwin B7377. Always verify compatibility with your specific engine serial number.

What are common parts needed for the 5088?

Common wear parts for the Case IH 5088 include: engine oil filters, fuel filters, hydraulic filters, air filters, fan belts, hydraulic seals, steering components (tie rod ends), clutch discs, and PTO clutch components.
