Case IH 4690 Tractor Parts

4690 parts and accessories

The Case IH 4690 tractor, manufactured from 1978 to 1981, was a powerful articulated four-wheel drive machine popular with farmers needing high horsepower for demanding tasks. Featuring a robust 300 HP turbocharged diesel engine, and delivering around 240 PTO horsepower, the 4690 was prized for its ability to handle large implements and cover ground quickly.

The Case IH 4690 was introduced in 1978 as part of the expansion of Case IH's large frame four-wheel drive tractor lineup. Production continued until 1981. It was designed to provide substantial power for large-scale farming operations. The tractor is powered by a Cummins V-8 diesel engine producing around 300 horsepower. Engine displacement is around 855 cubic inches. This model features a robust 12-speed manual transmission, offering a wide range of speeds for various field conditions. The PTO horsepower is rated at approximately 240 HP, available at 1000 RPM. Hydraulic capacity is significant, providing ample flow for large implements, typically around 45 GPM with multiple remote valves. While not equipped with a standard 3-point hitch, it could be outfitted with an optional hitch, typically a Category III. Common applications included primary tillage, pulling large planters and air seeders, and heavy row crop work. What distinguishes the 4690 from other models in the Case IH lineup of the time was its blend of raw power and relatively simple mechanical design, making it a reliable workhorse for its era.

Specifications

Engine	Cummins V-8 300 HP 855 ci Diesel
PTO HP	240 HP @ 1000 RPM
Transmission	Manual 12-Speed
Hydraulics	45 GPM, 2-4 remotes
3-Point Hitch	Category III (Optional), 6,500 lbs lift
Fuel Capacity	150 gallons
Weight	26,740 lbs
Years Produced	1978-1981

Maintenance Tips

Engine Oil & Filter: Change engine oil and filter every 250 hours of operation using a high-quality diesel engine oil that meets or exceeds the manufacturer's specifications.
Hydraulic System: Inspect hydraulic fluid levels regularly. Change hydraulic filters every 500 hours or as recommended by the manual. Use only approved hydraulic fluid to prevent damage.
Fuel System: Use a fuel filter/water separator. Drain any accumulated water from the fuel tank and separator regularly to prevent fuel system issues. Inspect fuel lines for cracks or leaks.
Seasonal Storage: Before storing the tractor for an extended period, fill the fuel tank to prevent condensation. Add a fuel stabilizer to the fuel. Disconnect the battery and store it in a cool, dry place.

History & Background

The Case IH 4690 was introduced in 1978 as part of a push to offer higher-horsepower tractors for larger farms. While it didn't see any major design changes during its production run, it established itself as a reliable and powerful machine, contributing to Case IH's reputation in the four-wheel drive tractor market.

Frequently Asked Questions

What engine is in the Case Ih 4690?

The Case IH 4690 is powered by a Cummins V-8 diesel engine, producing approximately 300 horsepower with a displacement of around 855 cubic inches.

What is the PTO horsepower on a 4690?

The PTO horsepower on the Case IH 4690 is rated at approximately 240 HP, and it operates at 1000 RPM.

What oil filter fits the 4690?

Common oil filter cross-references for the 4690 include Fleetguard LF3000, Baldwin B1441, and Wix 51794. Always verify compatibility with your specific engine before installation.

What are common parts needed for the 4690?

Common wear parts for the Case IH 4690 include engine oil filters, fuel filters, hydraulic filters, fan belts, hydraulic cylinder seal kits, tie rod ends, steering cylinders, and clutch disc/pressure plate components.
