Case IH 454 Tractor Parts

454 parts and accessories

The Case IH 454 tractor, manufactured from 1972 to 1975, was a reliable workhorse powered by a 44 HP diesel engine. With a PTO horsepower rating of approximately 39 HP, the 454 proved popular for its versatility in various farming tasks. Farmers appreciated its robust build and ease of operation, making it a staple in fields across the country.

The Case IH 454 was introduced in 1972 as part of the International Harvester (IH) line, later becoming Case IH after the merger. Production continued through 1975. It was powered by an IH BD-154 4-cylinder diesel engine, producing approximately 44 engine horsepower with a displacement of 154 cubic inches. This engine delivered ample power for a variety of farm tasks. The transmission was typically a gear-type with 8 forward and 2 reverse speeds, providing a good range for field work and transport. The PTO delivered approximately 39 horsepower at 540 RPM. The hydraulic system had a capacity of around 7.5 GPM, powering implements efficiently. It featured a Category I 3-point hitch. Common applications included row crop work, hay baling, livestock feeding, and light tillage. What distinguished the 454 from other models in the lineup was its size and horsepower, placing it in a sweet spot for farmers needing a capable but not overly large tractor for a wide range of tasks. It was a step up from smaller utility tractors but more economical than larger row-crop machines.

Specifications

Engine	International Harvester BD-154 44 HP Diesel
PTO HP	39 HP @ 540 RPM
Transmission	Gear, 8 forward and 2 reverse speeds
Hydraulics	7.5 GPM, 1-2 remotes
3-Point Hitch	Category I, 2,800 lbs lift capacity
Fuel Capacity	16 gallons
Weight	4,275 lbs
Years Produced	1972-1975

Maintenance Tips

Engine Oil & Filter: Change the engine oil and filter every 250 hours of operation using a high-quality oil meeting the manufacturer's specifications. Regular oil changes are crucial for engine longevity.
Hydraulic System: Check the hydraulic fluid level regularly and change the hydraulic filter every 500 hours. Use only the recommended hydraulic fluid type to prevent damage to the hydraulic components.
Fuel System: Use clean, high-quality fuel and inspect the fuel filter regularly. Drain any water or sediment from the fuel tank to prevent fuel system issues, especially in colder weather.
Seasonal Storage: Before storing the tractor for the off-season, stabilize the fuel, change the engine oil and filter, and grease all lubrication points. Disconnect the battery and store it in a cool, dry place.

History & Background

The Case IH 454 was introduced in 1972 as part of the International Harvester lineup, offering a reliable and versatile tractor option for farmers. While there weren't major redesigns during its production run, it maintained a reputation as a dependable machine. The 454 played a significant role in providing accessible power for small to medium-sized farming operations.

Frequently Asked Questions

What engine is in the Case Ih 454?

The Case IH 454 is equipped with an International Harvester BD-154 4-cylinder diesel engine, producing approximately 44 horsepower.

What is the PTO horsepower on a 454?

The PTO horsepower on the Case IH 454 is approximately 39 horsepower, operating at 540 RPM.

What oil filter fits the 454?

Common oil filter cross-references for the Case IH 454 include Fram PH2870A, Wix 51258, and Baldwin B2. Always verify compatibility with your specific tractor's configuration.

What are common parts needed for the 454?

Common wear parts for the Case IH 454 include engine oil filters, fuel filters, hydraulic filters, fan belts, hydraulic pump seals, steering components (tie rod ends), and clutch components (clutch disc, pressure plate).
