Case IH 3388 Tractor Parts

3388 parts and accessories

The Case IH 3388 tractor, manufactured from 1978 to 1981, was a powerhouse on the farm. Powered by a robust IH DT-466 diesel engine producing around 155 horsepower, it delivered reliable performance. Farmers appreciated its 135 PTO horsepower and its ability to handle demanding tasks, making it a popular choice for various agricultural applications.

The Case IH 3388 was introduced as part of the 30 series tractors in 1978, representing a significant advancement in tractor technology for its time. Production continued until 1981. Under the hood, it featured the International Harvester DT-466 inline 6-cylinder diesel engine. This engine delivered approximately 155 gross horsepower and displaced 466 cubic inches. The transmission was a partial powershift with 8 forward and 4 reverse gears, providing good flexibility for different field conditions. Its PTO delivered around 135 horsepower, available in both 540 and 1000 RPM configurations. The hydraulic system had a capacity of around 25 GPM, powering 3-point implements and remote hydraulic functions. The 3-point hitch was a Category II, offering a lift capacity of roughly 6,800 lbs. The 3388 was commonly used for row crop work, hay production, livestock operations, and general tillage. What distinguished the 3388 was its inline 6-cylinder engine, and partial powershift transmission, offering a balance of power and versatility.

Specifications

Engine	International Harvester DT-466 155 HP Diesel
PTO HP	135 HP @ 540/1000 RPM
Transmission	Partial Powershift 8F/4R
Hydraulics	25 GPM, 2 remotes
3-Point Hitch	Category II, 6800 lbs lift capacity
Fuel Capacity	75 gallons
Weight	14,200 lbs
Years Produced	1978-1981

Maintenance Tips

Change engine oil and filter every 250 hours of operation using a high-quality diesel engine oil that meets or exceeds API specifications.
Regularly inspect and service the hydraulic system, checking for leaks and replacing hydraulic filters according to the manufacturer's recommendations. Address leaks immediately to prevent further damage.
Maintain a clean fuel system by using clean fuel, replacing fuel filters regularly, and draining any water or sediment from the fuel tank periodically, especially before extended storage periods.
Before storing the tractor for the winter, drain the fuel tank, change the oil and filter, and add fuel stabilizer to prevent fuel degradation and corrosion.

History & Background

The Case IH 3388 was released in 1978 as part of a series of updated tractors from International Harvester before the Case IH merger. It represented a step forward in terms of power and operator comfort. This tractor contributed significantly to increased agricultural productivity in the late 1970s and early 1980s.

Frequently Asked Questions

What engine is in the Case Ih 3388?

The Case IH 3388 is equipped with an International Harvester DT-466 6-cylinder diesel engine, producing approximately 155 horsepower.

What is the PTO horsepower on a 3388?

The PTO horsepower on the Case IH 3388 is rated at 135 HP and offers both 540 and 1000 RPM options.

What oil filter fits the 3388?

The oil filter commonly used on the Case IH 3388 is a Fleetguard LF3349 or a Wix 51794. Cross-references may include Fram PH3985 or equivalent.

What are common parts needed for the 3388?

Common parts needed for the Case IH 3388 include engine oil filters, fuel filters, hydraulic filters, belts (fan belt, alternator belt), hydraulic seals, steering components like tie rod ends, and clutch parts such as the clutch disc and pressure plate.
