Case IH 300 Tractor Parts

300 parts and accessories

The Case IH 300 tractor, produced from 1955 to 1956, was a workhorse for many farms. It was powered by a 35 horsepower engine and had a PTO horsepower of around 30. Its versatility in row crop and general farm tasks made it a popular choice for farmers seeking a reliable and affordable tractor.

The Case IH 300 was introduced in 1955 as part of the International Harvester (IH) Farmall line, later becoming Case IH. Production lasted until 1956. It was designed as a utility tractor for various agricultural tasks. The engine was a 144ci IH C-144 gasoline engine producing approximately 35 engine horsepower. Some models were later equipped with diesel engines. The transmission was typically a 4-speed gear transmission, providing adequate speed ranges for field work. The PTO delivered around 30 horsepower, suitable for operating implements like rotary cutters and small balers. Hydraulics offered a flow rate of about 6.5 GPM. The 3-point hitch was Category I, allowing for the use of a range of implements. Common applications included row crop work, hay production, and general farm maintenance. The 300 differed from larger IH models by its smaller size, lower horsepower, and simpler design, making it ideal for smaller farms or secondary tasks on larger operations. The 300 set itself apart in the compact tractor segment.

Specifications

Engine	International Harvester C-144 35 HP Gasoline
PTO HP	30 HP @ 540 RPM
Transmission	4-speed Gear
Hydraulics	6.5 GPM, 1 remotes
3-Point Hitch	Category I, 1300 lbs lift
Fuel Capacity	14 gallons
Weight	3400 lbs
Years Produced	1955-1956

Maintenance Tips

Engine Oil & Filter: Change the engine oil and filter every 100-150 hours of operation. Use an oil specifically designed for gasoline engines, and replace the oil filter with a quality replacement to protect the engine.
Hydraulic System: Check the hydraulic fluid level regularly and inspect for leaks. Change the hydraulic fluid and filter according to the manufacturer's recommendations, typically every 500-600 hours.
Fuel System: Use fresh, clean fuel and add a fuel stabilizer if storing the tractor for extended periods. Clean the fuel sediment bowl regularly to prevent clogging.

History & Background

The Case IH 300 was released during the mid-1950s as a versatile utility tractor aimed at small to medium-sized farms. While it had a short production run, it established itself as a reliable and affordable tractor option. Its simple design and durable engine made it a popular choice during a period of agricultural mechanization.

Frequently Asked Questions

What engine is in the Case Ih 300?

The Case IH 300 is equipped with an International Harvester C-144 gasoline engine producing 35 horsepower. The engine has a displacement of 144 cubic inches.

What is the PTO horsepower on a 300?

The PTO horsepower on the Case IH 300 is approximately 30 horsepower, delivered at 540 RPM.

What oil filter fits the 300?

The common oil filter for the Case IH 300 is a Wix 51010 or a Fram PH8A. Always verify fitment before installation.

What are common parts needed for the 300?

Common wear parts for the Case IH 300 include engine oil filters, air filters, fuel filters, belts, hydraulic seals, steering components (tie rod ends), and clutch parts. Also, spark plugs and ignition points need regular replacement.
