Case IH 2670 Tractor Parts

2670 parts and accessories

The Case IH 2670 was a powerful agricultural tractor produced from 1973 to 1979, known for its robust performance and reliability. Powered by a 300 HP Cummins diesel engine, it delivered substantial power to the drawbar and PTO. Its high PTO horsepower made it a popular choice for farmers needing to run large implements in the field.

The Case IH 2670 was introduced in 1973 as a heavy-duty, four-wheel-drive tractor designed for large-acreage farming operations. Production continued until 1979. The tractor features a Cummins KT-1150 6-cylinder diesel engine, delivering approximately 300 horsepower. The engine has a displacement of 1150 cubic inches. The 2670 comes equipped with a robust 10-speed manual transmission providing a wide range of speeds for various field operations. It boasts a PTO horsepower of around 235 HP, capable of running at 1000 RPM. The hydraulic system has a capacity of approximately 34 GPM, offering ample flow for implements. While not equipped with a standard 3-point hitch, its drawbar pulling power was ideal for heavy tillage equipment, such as plows, discs, and cultivators. The Case IH 2670 distinguished itself from other models in the lineup by its sheer size and engine power, catering to farmers with extensive land holdings.

Specifications

Engine	Cummins KT-1150 300 HP Diesel
PTO HP	235 HP @ 1000 RPM
Transmission	Manual 10-Speed
Hydraulics	34 GPM, 2 remotes
3-Point Hitch	N/A, Drawbar only
Fuel Capacity	150 gallons
Weight	27,000 lbs
Years Produced	1973-1979

Maintenance Tips

Change the engine oil and filter every 250 hours of operation using the recommended oil type and a high-quality filter.
Regularly inspect and maintain the hydraulic system, checking for leaks and replacing hydraulic filters as needed to ensure optimal performance.
Monitor the fuel system, including fuel filters and injectors, to prevent clogging and maintain efficient fuel combustion. Use a fuel additive to combat ethanol related issues and prevent fuel gelling in winter.
Before seasonal storage, completely fill the fuel tank to prevent condensation, grease all lubrication points, and disconnect the battery to prevent discharge.

History & Background

The Case IH 2670 was launched in 1973 to address the growing demand for high-horsepower tractors capable of handling larger implements and covering more ground efficiently. There were no major redesigns during its production run, solidifying its reputation as a durable and reliable workhorse. It played a significant role in advancing agricultural productivity in the 1970s.

Frequently Asked Questions

What engine is in the Case Ih 2670?

The Case IH 2670 is powered by a Cummins KT-1150 6-cylinder diesel engine producing approximately 300 horsepower with a displacement of 1150 cubic inches.

What is the PTO horsepower on a 2670?

The PTO horsepower on the Case IH 2670 is rated at approximately 235 HP and operates at 1000 RPM.

What oil filter fits the 2670?

Common oil filter cross-references for the Case IH 2670 include Fleetguard LF3000, Baldwin P165, and Wix 51794. Always verify compatibility with your specific engine configuration.

What are common parts needed for the 2670?

Common wear parts for the Case IH 2670 include engine oil filters, fuel filters, air filters, hydraulic filters, fan belts, hydraulic cylinder seals, steering components, and clutch parts. Keeping these parts in good condition is essential for optimal tractor performance.
