Case IH 1570 Tractor Parts

1570 parts and accessories

The Case IH 1570 tractor, manufactured from 1973 to 1979, was a powerful workhorse for farmers. Powered by a 155 horsepower diesel engine, it provided ample power for various field tasks. Known for its robust build and reliable performance, the 1570's high PTO horsepower made it popular for operating demanding implements.

The Case IH 1570 tractor was part of the '70 Series' lineup, introduced in 1973. This model quickly gained a reputation for its ruggedness and power. It featured a Case-built 504 cubic inch (8.3L) inline 6-cylinder diesel engine, producing approximately 155 horsepower. The transmission was typically a gear-type, offering either a 8-speed forward, 4-speed reverse, or a 12-speed forward, 3-speed reverse option, providing flexibility for various field conditions. The 1570 delivered around 130 PTO horsepower, available with either a 540 or 1000 RPM PTO. The hydraulic system boasted a flow rate around 28 GPM, typically equipped with two remote valves for implement control. The 3-point hitch was a Category II, capable of lifting around 5,600 lbs. Common applications included row crop farming, tillage, and hay production. The 1570 stood out due to its simple, durable design, offering a blend of power and reliability that farmers appreciated during its production run.

Specifications

Engine	Case 504 cu in (8.3 L) 155 HP Diesel
PTO HP	130 HP @ 1000 RPM
Transmission	Gear Type 8/4 or 12/3
Hydraulics	28 GPM, 2 remotes
3-Point Hitch	Category II, 5600 lbs
Fuel Capacity	71 gallons
Weight	13,200 lbs
Years Produced	1973-1979

Maintenance Tips

Engine Oil & Filter: Change engine oil and filter every 250 hours using the recommended oil type for your climate and operating conditions.
Hydraulic System: Inspect hydraulic fluid levels regularly and change the hydraulic filter every 500 hours to prevent contamination and maintain hydraulic performance.
Fuel System: Use clean, high-quality diesel fuel and replace fuel filters at the recommended intervals (typically every 250-500 hours) to prevent fuel system issues.
Seasonal Storage: Before storing the tractor for the off-season, drain the fuel tank, add a fuel stabilizer, and lubricate all grease fittings to prevent corrosion and component degradation.

History & Background

Introduced in 1973, the Case IH 1570 represented a step up in power and capability for the Case tractor lineup. It remained largely unchanged throughout its production run, which ended in 1979. The 1570 is remembered as a dependable and hardworking tractor that contributed significantly to agricultural productivity during its era.

Frequently Asked Questions

What engine is in the Case Ih 1570?

The Case IH 1570 is equipped with a Case 504 cubic inch (8.3L) inline 6-cylinder diesel engine, producing approximately 155 horsepower.

What is the PTO horsepower on a 1570?

The Case IH 1570 delivers approximately 130 PTO horsepower. It was available with either a 540 or 1000 RPM PTO option.

What oil filter fits the 1570?

The Case IH 1570 typically uses a Case/IH oil filter part number A47247 or equivalents such as a Wix 51794 or a Fram PH3753. Always verify fitment with your parts supplier.

What are common parts needed for the 1570?

Common wear parts for the Case IH 1570 include engine oil filters, fuel filters, hydraulic filters, belts, hydraulic cylinder seal kits, steering components (tie rod ends, ball joints), and clutch components (clutch disc, pressure plate, throwout bearing).
