Case IH 1030 Tractor Parts

1030 parts and accessories

The Case IH 1030 tractor, manufactured from 1965 to 1969, was a popular choice for farmers needing a reliable workhorse. Powered by a 93 horsepower diesel engine, this tractor delivered ample power for various tasks. Its robust construction and 79 PTO horsepower made it well-suited for pulling implements and powering auxiliary equipment, enhancing its appeal among agricultural professionals.

The Case IH 1030 was introduced in 1965 and produced until 1969, part of the '30' series that aimed to deliver increased power and reliability. It features a 301 cubic inch (4.9L) 6-cylinder International Harvester diesel engine producing approximately 93 horsepower. The 1030 came standard with a manual transmission, offering either 8 forward and 4 reverse gears or an optional 16 forward and 8 reverse with the Torque Amplifier. The PTO delivers around 79 horsepower and operates at 540 RPM. Its hydraulic system has a capacity of approximately 12.5 GPM, feeding one or two remote valves. The 3-point hitch is a Category II, capable of lifting around 4,500 lbs. The 1030 was commonly used for various farming applications, including row crop work, hay baling, livestock operations, and tillage tasks like plowing and disking. Compared to other models, the 1030 offered a balance of power and size, making it a versatile machine for medium-sized farms. Its combination of a robust engine and functional hydraulics set it apart from some of the smaller tractors in the Case IH lineup.

Specifications

Engine	International Harvester 301 ci (4.9L) 93 HP Diesel
PTO HP	79 HP @ 540 RPM
Transmission	Manual 8/4 or 16/8
Hydraulics	12.5 GPM, 1-2 remotes
3-Point Hitch	Category II, 4500 lbs lift
Fuel Capacity	25 gallons
Weight	8,200 lbs
Years Produced	1965-1969

Maintenance Tips

Change the engine oil and filter every 150-200 hours using a high-quality diesel engine oil and a compatible filter.
Regularly inspect and service the hydraulic system, checking for leaks and ensuring the fluid is clean and at the correct level. Replace the hydraulic filter per the manufacturer's recommendations.
Maintain the fuel system by using clean fuel, replacing the fuel filter regularly, and draining any water or sediment from the fuel tank.
Before seasonal storage, drain the fuel tank, add fuel stabilizer, and lubricate all grease fittings to prevent corrosion and ensure easy startup in the spring.

History & Background

The Case IH 1030 was launched in 1965 as part of the '30' series, which aimed to modernize the Case IH tractor lineup. It provided a significant upgrade in power and features compared to earlier models. The 1030 played a key role in providing farmers with a reliable and capable tractor for a variety of agricultural tasks during the mid-to-late 1960s.

Frequently Asked Questions

What engine is in the Case Ih 1030?

The Case IH 1030 is powered by a 301 cubic inch (4.9L) 6-cylinder International Harvester diesel engine producing approximately 93 horsepower.

What is the PTO horsepower on a 1030?

The PTO horsepower on the Case IH 1030 is approximately 79 HP at 540 RPM.

What oil filter fits the 1030?

Common oil filter cross-references for the Case IH 1030 include Fram PH25, Wix 51773, and Baldwin B2. Always verify compatibility with your specific tractor using a parts catalog.

What are common parts needed for the 1030?

Commonly needed parts for the Case IH 1030 include engine oil filters, fuel filters, hydraulic filters, fan belts, hydraulic cylinder seals, steering linkage components, and clutch disc/pressure plate components.
