Case IH 2188 Combine Parts

2188 parts and accessories

The Case IH 2188 combine, produced from 1994 to 1999, was a popular choice for farmers seeking reliable harvesting performance. Powered by a robust 235 HP Cummins engine, it offered header widths up to 30 feet. Its rotary separator design significantly improved grain separation and reduced losses, making it well-suited for various crops.

The Case IH 2188 combine was manufactured from 1994 to 1999, building upon the success of previous Axial-Flow models. It was powered by an 8.3L Cummins 6CTA 8.3 diesel engine producing 235 horsepower. The 2188 utilizes a rotary threshing and separation system with a 30-inch diameter rotor and a 105-inch long cage, providing excellent grain quality and reduced grain loss. It boasts a grain tank capacity of approximately 225 bushels and an unloading auger capable of unloading at a rate of around 1.9 bushels per second (approximately 114 bu/min). Available header widths ranged from 15 to 30 feet, allowing for versatility across different field sizes and crop types. Options included a chopper and spreader for residue management. The cab offered improved operator comfort and visibility compared to earlier models. The 2188 excelled at harvesting a wide variety of crops including corn, soybeans, wheat, and other small grains due to its efficient threshing and separation capabilities.

Specifications

Engine	Cummins 8.3L 235 HP Diesel
Separator Type	Rotary - 30-inch diameter rotor, 105-inch long cage
Grain Tank	225 bushels
Unloading Rate	114 bu/min
Header Widths	15-30 ft
Fuel Capacity	150 gallons
Weight	22,500 lbs
Years Produced	1994-1999

Maintenance Tips

Regularly inspect and adjust concaves to ensure proper threshing and minimize grain loss.
Check and maintain proper belt and chain tension to prevent slippage and premature wear.
Clean sieves and chaffers frequently to remove debris and maintain optimal cleaning performance.
Grease all bearings regularly according to the manufacturer's recommendations to prevent failures.
Before each harvest season, thoroughly inspect all components, including belts, chains, bearings, and knives, and replace worn parts as needed.

History & Background

Introduced in 1994, the Case IH 2188 was a significant advancement in combine technology, offering increased capacity and efficiency over its predecessors. It represented a continuation of the Axial-Flow rotary combine design, which had become a staple in the agricultural industry. The 2188 helped solidify Case IH's position as a leader in combine harvester innovation.
