Case IH 1682 Combine Parts

Jump to Parts

The Case IH 1682 combine, produced from 1987 to 1992, was a popular choice for farmers seeking a reliable and versatile grain harvesting solution. Powered by a robust diesel engine delivering around 215 horsepower, the 1682 could accommodate header widths up to 30 feet, making it suitable for a range of field sizes. Its conventional threshing system offered efficient grain separation and contributed to its reputation for durability and ease of maintenance.

The Case IH 1682 was introduced in 1987 and continued in production until 1992, building upon the legacy of previous Case IH combines. It was equipped with an International Harvester (IH) DT-402 naturally aspirated diesel engine, producing approximately 215 horsepower with a displacement of 402 cubic inches (6.6 liters). The 1682 utilized a conventional threshing system with a 43-inch wide cylinder and a large cleaning shoe area. The grain tank capacity was rated at 205 bushels, and it featured a fast unloading auger capable of unloading at approximately 1.5 bushels per second (90 bu/min). Available header widths ranged from 13 to 30 feet, providing flexibility for different crop and field conditions. The 1682 offered options for straw choppers and spreaders to manage crop residue. The cab provided basic operator comfort with air conditioning available as an option. The Case IH 1682 proved to be effective at harvesting a variety of crops, including wheat, soybeans, and corn, due to its efficient threshing and cleaning system.

Specifications

Engine	International Harvester (IH) DT-402 215 HP 402 cu in Diesel
Separator Type	Conventional - 43-inch Cylinder Width
Grain Tank	205 bushels
Unloading Rate	90 bu/min
Header Widths	13-30 ft
Fuel Capacity	85 gallons
Weight	19,000 lbs
Years Produced	1987-1992

Maintenance Tips

Concave Adjustment: Regularly inspect and adjust the concave clearance based on the crop being harvested to optimize threshing performance and minimize grain damage.
Belt and Chain Tension: Check and maintain proper tension on all belts and chains, especially the header drive, feeder chain, and separator belts, to prevent slippage and ensure smooth operation.
Sieve and Chaffer Cleaning: Clean the sieves and chaffer screens frequently to remove debris and ensure proper airflow for efficient grain separation, especially when harvesting in dusty conditions.
Bearing Greasing: Regularly grease all bearings according to the manufacturer's recommendations to prevent premature wear and failure, paying close attention to bearings on the header, feeder house, and separator.

History & Background

The Case IH 1682 was released in 1987, representing an evolution of Case IH's combine technology. It built on the success of previous models and offered advancements in engine performance and grain handling. The 1682 solidified Case IH's position as a major player in the combine harvester market during the late 1980s and early 1990s.

Frequently Asked Questions

What engine is in the Case Ih 1682?

The Case IH 1682 is powered by an International Harvester (IH) DT-402 naturally aspirated diesel engine, producing approximately 215 horsepower with a displacement of 402 cubic inches (6.6 liters).
