Case IH 1440 Combine Parts

1440 parts and accessories

The Case IH 1440 combine, produced from 1979-1984, was a popular choice for farmers seeking a reliable and efficient conventional combine. Powered by an engine producing around 155 horsepower, it handled a variety of crops with ease. It was typically equipped with header widths ranging from 13-20 feet, offering flexibility for different field sizes and crop conditions.

The Case IH 1440 combine, manufactured from 1979 to 1984, quickly earned a reputation for its robust design and straightforward operation. It was powered by an International Harvester DT-402 six-cylinder diesel engine, delivering approximately 155 horsepower with a displacement of 402 cubic inches. The 1440 utilized a conventional threshing system with a 43-inch wide cylinder, featuring rasp bars and a concave to separate grain from the crop material. It featured a grain tank capacity of around 165 bushels and an unloading rate of approximately 70 bushels per minute. Header widths available ranged from 13 to 20 feet, allowing farmers to tailor the combine to their specific needs. Options included a straw chopper or spreader for residue management. The cab provided operators with basic controls and monitoring capabilities, focusing on functionality and ease of use. The Case IH 1440 excelled in harvesting wheat, soybeans, and corn, proving to be a versatile and dependable machine.

Specifications

Engine	International Harvester DT-402 155 HP 402 CID Diesel
Separator Type	Conventional - 43-inch Cylinder
Grain Tank	165 bushels
Unloading Rate	70 bu/min
Header Widths	13-20 ft
Fuel Capacity	75 gallons
Weight	15,800 lbs
Years Produced	1979-1984

Maintenance Tips

Concave Adjustment: Regularly inspect and adjust concave clearance based on the crop being harvested. Proper adjustment minimizes grain loss and maximizes threshing efficiency.
Belt and Chain Tension: Routinely check belt and chain tension throughout the combine, particularly on the header, feeder house, and threshing mechanism. Loose belts and chains can cause slippage and damage.
Sieve and Chaffer Cleaning: Clean the sieves and chaffer regularly to remove debris and ensure proper air flow. Clogged sieves can lead to excessive grain loss over the back.
Bearing Greasing: Follow the recommended greasing schedule for all bearings on the combine, paying close attention to bearings on rotating components like the cylinder, augers, and cleaning fan.

History & Background

Introduced in 1979, the Case IH 1440 was a significant model in the Case IH lineup, offering a mid-sized conventional combine option. While there weren't major redesigns during its production run, it represented a solid design that built upon the success of previous IH combines. It served as a reliable and affordable option for many farmers during its time.

Frequently Asked Questions

What engine is in the Case Ih 1440?

The Case IH 1440 is equipped with an International Harvester DT-402 six-cylinder diesel engine producing approximately 155 horsepower with a 402 cubic inch displacement.
