John Deere X390 Riding Mower Parts

Jump to Parts

The John Deere X390 is a popular riding mower known for its smooth ride and powerful performance. Typically manufactured between 2016 and 2020, this model features a Kawasaki engine delivering around 22 horsepower. It was primarily offered with a 48-inch mower deck, making it ideal for medium to large-sized lawns.

The John Deere X390 was introduced as part of the X300 series, offering a step up in features and performance compared to lower-end models. It's powered by a Kawasaki FS691V engine, a 22 HP (16.4 kW) V-twin gasoline engine with a displacement of 726cc (44.3 cu-in). This model utilizes a hydrostatic transmission, providing smooth and responsive speed control. The X390 was primarily available with a 48-inch Accel Deep mower deck, designed for superior cut quality and even clipping dispersal. Key features of the X390 include power steering, hydraulic deck lift, and a comfortable high-back seat. This model is well-suited for residential use on properties ranging from half an acre to several acres, offering a balance of power, comfort, and maneuverability. Its robust engine and durable construction distinguish it from more basic riding mowers in the John Deere lineup.

Specifications

Engine	Kawasaki 22 HP 726cc V-Twin
Transmission	Hydrostatic
Deck Size	48 inches
Ground Speed	0-5.5 mph forward, 0-4 mph reverse
Fuel Capacity	4.4 gallons
Weight	633 lbs
Years Produced	2016-2020 (approximate)

Maintenance Tips

Belt Inspection: Regularly inspect the mower deck and drive belts for wear and tear. Replace belts every 200-300 hours of use, or sooner if cracks, fraying, or slippage are observed.
Blade Sharpening: Sharpen the mower blades at least twice per season, or more frequently if you mow over sandy or abrasive terrain. Dull blades tear the grass, leading to an unhealthy lawn.
Filter Changes: Change the engine oil and oil filter every 50 hours of operation. Replace the air filter annually or more often if operating in dusty conditions.
Seasonal Storage: Before storing the mower for the winter, stabilize the fuel, change the oil and filter, and disconnect the battery. Store the mower in a dry, protected location.

History & Background

The John Deere X390 was introduced in 2016 as a mid-range model within the X300 series. It offered improvements over the X380, primarily through its enhanced hydraulic deck lift and power steering. It remained a consistent offering in the lineup for several years, providing a balance of features and value.

Frequently Asked Questions

What size deck does the John Deere X390 have?

The John Deere X390 is primarily equipped with a 48-inch Accel Deep mower deck.

What engine is in the John Deere X390?

The John Deere X390 is powered by a Kawasaki FS691V, 22 HP V-Twin gasoline engine.

What belt do I need for my John Deere X390?

The John Deere X390 uses a specific mower deck belt and drive belt. Consult your owner's manual or a parts diagram to determine the correct part numbers. Commonly used deck belt part numbers include M154621. Contact us with your mower's serial number for accurate belt identification.

What blades fit the John Deere X390?

The John Deere X390 with the 48-inch deck uses three blades, each approximately 16.5 inches long. These blades are typically high-lift blades designed for efficient bagging and side discharge.

Showing 1-24 of 41 products

Sort by:
