John Deere L130 Riding Mower Parts
Browse John Deere L130 Riding Mower replacement parts. Everything from routine maintenance items to hard-to-find components.
The John Deere L130 riding mower, produced from 2002 to 2005, was a popular choice for homeowners with larger lawns. Powered by a dependable Kawasaki 17 HP engine and featuring a wide 48-inch deck, the L130 offered a great balance of power and cutting capacity. Its smooth hydrostatic transmission and comfortable design made mowing a breeze.
About the L130
The John Deere L130 was introduced in 2002 as part of the L-Series line of lawn tractors. Designed for residential use, the L130 provided a step up in power and cutting width compared to the smaller models in the series. It was equipped with a Kawasaki FH491V engine, a 17 horsepower twin-cylinder engine known for its smooth operation and reliability. The L130 featured a hydrostatic transmission, providing effortless speed control. The 48-inch mower deck offered a wide cutting swath, reducing mowing time on larger properties. Key features included electric blade engagement, a comfortable high-back seat, and a durable frame. Compared to other models in the L-Series, the L130 offered a larger deck and more powerful engine, making it suitable for homeowners with bigger lawns and slightly more challenging terrain. The L130 offers the same features and benefits of the L120 with a bigger deck. It was discontinued in 2005.
L130 Specifications
| Engine | Kawasaki 17 HP 491cc V-Twin |
|---|---|
| Transmission | Hydrostatic |
| Deck Size | 48 inches |
| Ground Speed | 0-5.5 mph |
| Fuel Capacity | 3.0 gallons |
| Weight | 540 lbs |
| Years Produced | 2002-2005 |
L130 Maintenance Tips
- Change the engine oil and filter every 50 hours of operation or at least once a year.
- Sharpen or replace the mower blades annually or more frequently if they become dull or damaged. Dull blades tear the grass instead of cutting it cleanly.
- Inspect and replace the mower deck belt and drive belt every 200 hours of operation or every two years. Look for signs of wear, cracking, or fraying.
- Before storing the mower for the winter, stabilize the fuel, change the oil and filter, and disconnect the battery. Store the mower in a dry place.
L130 History & Background
The John Deere L130 was introduced in 2002 and remained in production until 2005. It was positioned as a mid-range model in the L-Series, offering a larger deck and more powerful engine than entry-level models. There were no major design changes during its production run.
Frequently Asked Questions
Which spindle assembly is recommended for the John Deere L130's 48-inch deck?
For the 48-inch mower deck on the John Deere L130, the recommended spindle assembly is B1JD37 - Assembly, Spindle.
What starter motor fits the John Deere L130 riding mower?
For the John Deere L130, a suitable replacement starter motor is AM132702 - Starter, 12V, CCW, 9T, 0.6KW, (New), also cross-referencing to parts like AM108390 and AM131296.
What belt do I need for my John Deere L130?
For the mower deck, the John Deere L130 typically uses the GX20072 - Belt, Blade Drive. For the main traction drive belt, consider the GX20006 - Belt, Traction Drive, Mower.
What blades fit the John Deere L130?
For the 48-inch deck on the John Deere L130, you'll typically need three blades. We recommend the B1JD6014 - BLADE-MOWER, XHT, 17", 13/32" or the heavy-duty B1PD5044 - BLADE-MOWER, PRED, 17", 11/16".

AM132702 - (New) 0.6KW 9T CCW 12V Starter
SKU: AM132702
9 in stock

AD2062R - Light Bulb
SKU: AD2062R
115 in stock

LF16108J - Lube (QTY 1) Filter
SKU: LF16108J
Out of stock

LF16108 - Lube (QTY 12) Filter
SKU: LF16108
85 in stock

GY20496 - High Back Lawn Tractor Seat
SKU: GY20496
1148 in stock

B1SB484 - Ball Bearing
SKU: B1SB484
635 in stock

B1JD23 - V-Idler
SKU: B1JD23
81 in stock

B1JD22 - Flat Idler
SKU: B1JD22
398 in stock

B1JD20 - Flat Idler
SKU: B1JD20
414 in stock

AM118447 - Idler Pulley
SKU: AM118447
178 in stock

GY20492 - Rh Draglink Assy Adjustable # Rod
SKU: GY20492
343 in stock

GY20491 - LH Draglink Assy Adjustable # Rod
SKU: GY20491
211 in stock

GX24864 - JOHN DEERE
SKU: GX24864
188 in stock

GX21994 - Steering Shaft Bushing
SKU: GX21994
1796 in stock

GX21718 - Trunnion
SKU: GX21718
577 in stock

GX21694 - Blade Mounting; 5/8" Lock Nut
SKU: GX21694
1810 in stock

GX21582 - Mower Deck Belt Tension Spring
SKU: GX21582
305 in stock

GX20053 - Steering Pinion Gear
SKU: GX20053
85 in stock

GX20052 - Steering Sector Gear
SKU: GX20052
397 in stock

B1JD37 - Spindle Assembly
SKU: B1JD37
1407 in stock

B1JD36 - Spindle Mounting Bolt
SKU: B1JD36
3024 in stock

A64624 - External Snap Ring
SKU: A64624
57 in stock

B1OF286A - Oil Filter
SKU: B1OF286A
463 in stock

B1OF286 - Oil Filter
SKU: B1OF286
7129 in stock
